C Purlin Roll Forming Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
HIGHFULL
Place of Origin:
China
Model Number:
HF
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
C Channel Steel Roll Forming MachineNegotiableMOQ: 1 Set -
C Section Steel Cold Roll Forming MachineNegotiableMOQ: 1 Set
-
U Track Cold Roll Forming MachineNegotiableMOQ: 1 Set
-
C/Z Purline Steel Interchangeable Cold Roll Forming MachineNegotiableMOQ: 1 Set
-
C Shaped Steel Purline Roll Forming MachineNegotiableMOQ: 1 Set
Brand Name
HIGHFULL
Place of Origin
China
Model Number
HF
C purlin roll forming machine:
1.High Quality(No damage parts)
2.No.1 Service(with warranty and one year guarantee repair)
1.High Quality(No damage parts)
2.No.1 Service(with warranty and one year guarantee repair)
C purlin roll forming machine, roll forming machine, C profile steel roll forming machine
Technical specifications:
| Material Width | 500mm max |
| Material Thickness | 2.0mm- 3.0mm |
| Forming speed | 12m-15m/min |
| Forming stations | 15 |
| Material of the main shaft and rollers |
forged Cr12, queching HRC58-62° |
| Material of hydraulic cutter |
Cr12 Mov |
| Power of main motor | 11kw |
| Power of hydraulic station | 7.5kw |
| Electric control system | PLC |
| Driving system |
chain driven by motor reducer |
| Dimensions |
about 10500mmx1500mmx1400mm. |
| Function | forming C purlin |
C purlin forming machine
C80-C300 (C80,C100,C120,C140,C150,C160,C180,C200,C250,C300), can design and make the machine according to the requirement of the clients.
The equipment include
1. Un-coiler, 1 set
2. Main Roll forming machine, 1 set
3. Hydraulic cutting, 1 set
4. Hydraulic station, 1 set
5. Electric controlling system, 1 set
6. Product rack (un-powered), 1 set
7. Instruction Book, 1 piece
