Help CenterSG12A Heating Tube Compressing Machine
Related Products
SG12A tube compressing/reducing machine is using the high-quality gear motor as its power, which is sent to the gear case through the double spindle. The cross transmission shaft is connected with the roller seat. Using rolling reducing method, tubes after reduced with smooth surface, roundness ±0.05mm, straightness accuracy less than 3-5mm within 1000mm. The roller head structure is universal with SG12B, which can be separated with the machine frame and to be changed as a whole. One motion seat can wear several roller seat assemblies of different standards to achieve quick changing of the standard to fit producing need of different tubes.
Features: steady, high speed, fast mold-changing, low noise
MAIN TECHNICAL PARAMETER:
1.Rotating speed of Roller: 60rpm
2.Roller dimension: outside diameter φ98.5mm；inside diameter φ45mm；thickness 38mm
3.Center distance between rollers: 115 mm (with adjustable distance 0.5 mm downward)
4.Motor power (single): 1.1KW
5.Source power: 380V 50HZ 9.5KW
