Open Type Perkins Generator Set/Power Generator 1500KW 50Hz Water-cooled

Diesel Generator Set Data

Manufacturer: Jiangsu Starlight Generating Equipments Co.,Ltd

Prime Power: 1500KW/1875KVA

Rated Current: 2455(A)

Rated Frequency: 50（Hz）

Start-up time: 5～6（s）

Power Factor: 0.8（Lag）

Rated Voltage: 400/230（V）

Standard Features

Engine: PERKINS  4016TAG1A

Radiator 50℃ max

Fans are driven by belt, with safety guard

24V charge alternator

Dry type air filter, fuel filter, oil filter

Alternator: single bearing alternator

IP23, insulation class H/H

Main line circuit breaker

Standard control panel

Absorber

Muffler

User manual

Diesel Engine Data

Manufacturer:  PERKINS

Model: 4016TAG1A

Output Power: 1691KW

Rated Speed: 1500（r/min）

Cycle: 4 stroke

Cylinder Arrangement: 16in line

Displacement: 61.12L

Bore and Stroke: 160*190（mm）

Compression Ratio: 13.6:1

Governor Type: Electronic

Start battery voltage: 24V DC

Air Intake System

Air Intake System: Turbo

Burning Capacity: 107 m³/min

Exhaust System

Exhaust Gas Flow: 252m³/min

Exhaust Temperature: 400℃

Max Back Pressure: 10.2kpa

Fuel System

Fuel System: Direct injection

100%( Prime Power) Load: 207g/kwh

50%( Prime Power) Load: 222g/kwh

Oil System

Total Oil Capacity: 237L

Cooling System

Cooling Way: Water-cooled

Total Coolant Capacity: 214L

Thermostat: 71-85℃

Max Water Temperature: 101℃

Alternator Data

Manufacturer: STARLIGHT/STAMFORD/SIEMENS/MARATHON/ENGGA/KEPU

Excitation Mode: Brushless and self- exciting

Number of phase and Access Act: 3-phase 4-wire

Connecting Type:“Y” type connecting

Alternator Capacity: 1875KVA

Alternator Efficiencies: 95％

Overload:（PRP）110% load can run 1h

Protection Level: IP22-IP23

Insulation Class, Temperature Rise: H/H

Telephone Influence Factor (TIF): ＜50

THF: ＜2%

Voltage Regulation, Steady State: ≤±1%

Air Cooling Flow: 0.216m3/s

Altitude: ≤1000m
