Rosemount™ 3051S Coplanar™ Pressure Transmitter

Introduction

The Rosemount 3051S Coplanar™ Pressure Transmitter is designed with the patented Coplanar technology and is the no-equal solution for pressure, flow and level measurements. This scalable platform seamlessly integrates with manifolds, primary elements and seal solutions and optimizes performance for accurate differential, gage and absolute pressure measurements. With the SuperModule™ platform, this transmitter resists overpressure and line pressure effects to maintain unmatched performance.

Specifications

Warranty

Up to 15-year limited warranty

Rangedown

Up to 200:1

Communication Protocol

4-20 mA HART,WirelessHART, FOUNDATION fieldbus

Measurement Range

Up to 2000psi (137,89 bar) Differential, Up to 2000psig (137,89 bar) Gage, Up to 4000psia (275,79 bar) Absolute

Process Wetted Material

316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated Alloy 400, Gold-plated 316L SST

Diagnostics

Basic Diagnostics, Power Advisory Diagnostics, Advanced Diagnostics

Certifications/Approvals

SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE, hazardous location, see full specs for complete list of certifications

Features

Patented Rosemount Coplanar technology offers optimized performance as a pressure, DP Flow and DP Level solution

Best-in-class, scalable architecture enhances performance, functionality and process connections

Transmitter arrives fully assembled and leak tested for simple installation and maintenance

All-welded hermetic SST SuperModule platform resists overpressure and line pressure effects to ensure 0.025% accuracy

Ultra and Ultra for Flow performance classes deliver 15-year stability and 15-year limited warranty

200:1 rangedown produce reliable measurements and wide application flexibility

Integrates seamlessly with 4-20 mA HART®, WirelessHART®, FOUNDATION™ fieldbus protocols for application flexibility

SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations

Advanced diagnostics provide diagnostic coverage to detect electrical loop issues and abnormal process conditions

Remote display and interface offers easy access to process and device information
