Hammer Mills & Rock CrushersWhat is a Hammer Mill?
A hammer mill is a crusher that can grind, pulverize, and crush a wide range of materials. This rock crusher machine employs a rain of hammer blows to shatter and disintegrate the material. Hammer mills produce a finish product size that is dependent upon...
1. Openings in perforated screens or grate bars
2. Number, size and type of hammers
3. Grinding plate setting
4. Rotor speed
The serviceability of a Lingheng Machine is second to none. Standard service can be performed with common hand tools. We have product contact points available in carbon and stainless steel. Our rock crusher machines can be rebuilt over and over, saving you money. The special combination of features in a Lingheng Hammer mill is the result of over 30 years' experience in the field. Wood hammer mills, also called wood hogs are special heavy duty. Hammer mills specifically designed to process wood and fibrous waste without the use of high maintenance knives. Our machines have simple designs with rugged construction that make them easy to operate and maintain.
Lingheng Hammer mill Features· Large opening for flexibility
· Fully lined crushing chamber for longevity
· Liners are bolted for easy change out
· Grate bars and screens for accurate product sizing that are easily replaceable
· Hammers or rings allowing flexibility
· Forged alloy steel and extreme duty shaft allowing reduced vibration and longer bearing life
· Positive lock housing for extra security from blow outs and dusting
· Adjustable grinding plate for process control
· Multiple rotor configurations to suit any material
· Large discharge opening
Technical Data of hammer crusher
Model |
Feeding |
Discharging |
Capacity |
Motor |
Total |
Dimensions |
PCØ400*300 |
5-10 |
11 |
0.8 |
900*670*860 |
||
PCØ600*400 |
10-22 |
22 |
2.26 |
1200*1050*1200 |
||
PCØ800*600 |
18-40 |
55 |
4.8 |
1310*1180*1310 |
||
PCØ1000*800 |
25-50 |
75 |
5.9 |
1600*1390*1575 |
||
PCØ1000*1000 |
30-55 |
90 |
8 |
1800*1590*1775 |
||
PCØ1200*1200 |
50-80 |
132-160 |
19.2 |
2060*1600*1890 |
||
PCØ1400*1400 |
50-100 |
280 |
32 |
2365*1870*2220 |
||
PCØ1600*1600 |
100-150 |
480 |
37.5 |
3050*2850*2800 |
· Hammer Crusher
· Hammer Crusher is the most suitable to crush each brittle materials like coal, gangue, coke, slag, sandstone, shale and limestone. It has the following features : the higher production efficiency, low noise and low vibrations for easy operation.
