Aoding Newest Instrument Fluorescence Dissolved Oxygen DO Meter

Our Company

Yancheng Aoding Instrument Manufacturing Co., Ltd. is located in the beautiful and rich coastal city.Since it established, the company has cooperated with famous universities and research institutes in Jiangsu, Shanghai and other places.

From the components to the final assembly, the factory has gone through strict screening and process quality control, ensuring that the products can be operated safely, reliably and with high quality to the user. The goal we have been pursuing: accurate product measurement, reliable operation, simple operation, low maintenance, little spare parts, convenient installation and good service.

Our products in the global market has been used successfully for more than 10 years, as the industry leader, we will continue to provide a reliable instrument and professional services to global customers, and constantly improve the technological innovation and product quality to meet the needs of different customers.

Product Description

DO-6383YG dissolved oxygen sensor adopt fluorescence measurement of dissolved oxygen and emit blue light on the screen. The fluorescent substance is stimulated to emit red light. The oxygen concentration is inversely proportional to the time when the fluorescent substance returns to the ground state. The dissolved oxygen measured by this method does not produce oxygen consumption when measured, the data is stable, the performance is reliable, the interference is not exist, the installation and correction are simple.

The product is widely used in wastewater treatment plants, waterworks, water stations, surface water, aquaculture, industrial and other fields of dissolved oxygen monitoring. The configured waterproof high-performance controller can easily receive the data measured by the sensor. The user can also realize the 4-20mA analog output through the interface configuration and calibration of the controller. It realize relay control, digital communication and other function.

Main Feature

Secondary table installation: wall-mounted type

Electrode installation: flow/immersion/flanged/duct type

Standard configuration: a second table and a fluorescent dissolved oxygen electrode

Main feature:

Maintenance free.

No need to supply electrolyte.

It doesn't have to be washed regularly.

In most applications for at least one year, the sensor cap is not calibrated or replaced.

Less measurement drift.

There is no need to guarantee the sample flow rate to ensure the measurement accuracy.

Waterproof and dustproof design: protection grade IP65, it is suitable for outdoor use.

Alarm function: alarm signal isolation output, alarm upper and lower limit can be set arbitrarily.

Network function: isolated current output and RS485 communication interface.

Technical Parameters

Display mode: LCD display, menu operation in Chinese and English (Chinese and English can be switched)

Measuring range : (0 ~ 20) mg/L; (-10 ~ 55) ℃

Resolution: 0.001 mg/L, 0.1 ℃

Accuracy: ± 0.1mg/L, ± 0.5℃

Current isolation output: 4~20 mA or 0~10 mA (load <750);

Alarm relay: AC220V, 3A, alarm signal isolated output

Communication interface: isolated RS485 (optional)

Power supply: AC220V ± 22V, 50Hz ± 1Hz;

Protection grade: IP65

Working conditions: temperature 0℃ to 60 ℃, relative humidity≤ 90 %

Power-down save: > 10 years

Weight & Size: 2 kg, 186 * 131 * 90 mm

Application

It is widely used in wastewater treatment, pure water, circulating water, boiler water system ,electronic, electroplating, printing and dyeing, chemical, food, pharmaceutical and other fields in the process, the large-scale sewage treatment plant of industrial process monitoring applications such as outstanding performance.
