5T FRP Hydraulic Pultrusion Machine on Sale China(mainland)

The introduction of the characteristics and the complication of FRP product hydraulic pultrusion machine

The equipment adopts the hydraulic drive. It has the characteristics of traction speed stepless adjustment and stability with low speed. It is mainly used in the production of FRP products. It is especially suitable for FRP products such as cable bridge with great section, I-steel, guardrail and so on. It is the ideal FRP equipment.

The component and the auxiliary equipment of FRP product hydreulic   pultrusion machine

FRP pultrusion device consists of machinery, hydraulic  pressure and electric. The mechanical section consists of heating frame, terial trough, frame and two clamping gantries。The hydraulic section consists of two independent hydraulic systems which consists of grip cylinder, push action cylinder, oil pump ,motor, electromagnetic valve, speed control valve, overflow valve, oil filter and oil reservoir et. The electric section consists of heating controller, temperature controller, control box and so on.   The auxiliary equipment consists of electromagnetic speed mixer, pneumatic automatic cutting machine, electric mat slitter and so on. These formed the whole FRP production line.

The principle and the characteristic of FRP production hydraulic pultrusion machine

The working principle of FRP product hydraulic pultrusion machine is as follows. Firstly, raw material is forming by heating in the mould. Then, it will be pulled out by two clamping traction gantries which alternating operation. Finally, we will get all kinds of FRP productions.

The characteristics of FRP product hydraulic pultrusion machine are strong traction, Double hydraulic system, the manufacturing technique of convenient adjusting, admirable hydraulic system and the components with high sensitivity and low fault rate which have a high profile brand. These features can ensure the quality of products.

The main technical index of FRP production hydraulic pultrusion machine

Max pultrusion capacity: 10T, 20T, 30T-50T (Custom)

Max pultrusion capacity: 10T, 20T, 30T-50T (Custom)

Pultrusion speed: 0.1-0.6m/min(adjustable)

Pultrusion maximum working pressure of the hydraulic station: 6.3MPa

Pultrusion working pressure of the hydraulic station:2-6.3MPa

Pressure:0.4-0.6MPa

Number of heating zone: 3 zones&6zones

Mold heating temperature range: 0-200℃

Pump motor pump:2.2kw(2sets)  3.0kw(2sets) (Custom)

1.      Hot put power: 3-15kw

2.      Power requirement: 3*380+N(4*10mm2) (Custom)

3.      Working mode: Single, Synchronism, Alternation (3modes)

4.      Transmission medium in the hydraulic system: YB-N46 antiwear hydraulic oil in summer, 32# hydraulic oil in winter
