Glazed Tile Roll Forming Machine

Brief introduction:
Glazed Tile Roll Forming Machine can produce various of steel roof and wall panel, it is a new building materials, the products are widely used as the roof and wall of factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, etc. It has many advantages, such as easy installation, short building period, beauty, light weight but high strength.

Glazed Tile Roll Forming Machine
1. High efficiency
2. Lower cost
3. Long life time: 30years
4. Low energy consumption
5. PLC control, Panasonic or Siemens or eura
6. Easy operation
7. Beautiful and best quality
Parameters of the Glazed Tile Roll Forming Machine :
1. Suitable material: Color steel plate, Galvanized Board, Aluminum Plate, etc.
2. Suitable thickness: 0.3-0.8mm or other thickness
3. Forming specifications: Depending on specific requirements of customers
4. Forming speed: 0-3m/min
5. Main motor power: 4Kw (depending on specific requirements of users)
6. Cutting mode: Hydraulic cutting
7. Hydraulic station power: 4Kw (depending on specific requirements of users)
8. Control system: PLC systems from Mitsubishi, Schneider and Panasonic products, electrical appliances of famous brands
9. Way of drive: One inch chain
10. Optional accessories: Hydraulic uncoiler.
11. Material of roller: High grade 45# forged steel plated with hard chrome plating
