XJ1218 Advertising Equipment With Application

Specifications

XJ1218 Advertising Equipment With Wide Application

 Proper features:

1) Integrated optimization design, high quality aluminum alloy frame, which ensure solid and warp-proof.

2) Flexible, precision, introducing un-space ball screw from Germany technology, align with high power driving motor, imported coupling, movement is more stable and high precision for long life.

3) High power non-brushing motor, N-CVT, power saving, lower noise, strong cutting capability, which ensuring batch process for long time.

4) Restoring function enable the machine stop running automatically while power off, and automatically resume to work when power on, and also can store the break point from which for later operation to start, with the function of anticipating working time, auto tool sensor, the rotating speed and processing depth could be adjusted optionally..

Technique parameter:

working area:                     1200*1800*80mm

Spindle power:                    1500w / 400Hz / 24000rpm/min

Rated power:                       350w

Power source request:         AC220v 50Hz (110v 50Hz)

Carving range:                     1200*2400*70mm

Carving speed:                     0-8000mm/min

Cutting tool diameter:           3.175mm/6mm

Engine bed resolution:          0.02mm

Mechanical drive:                 XYZ ball bearing guide screw

Code form:                           G code, HPGL

Software:                             weitai/type3/Artcam/CAXA

Weight:                                500kg
