Home > Products > Laser Machine > Factory Direct Sale New Style Wood Acrylic CO2 Laser Engraving Machine Desktop Laser Cutting Machine
Factory Direct Sale New Style Wood Acrylic CO2 Laser Engraving Machine Desktop Laser Cutting Machine
- Qingdao Shanghai Tianjin
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Condition | New | Laser Type | CO2 | |
| Engraving Area | 1300*900mm | Engraving Speed | 1200mm/s | |
| CNC or Not | Yes | Cooling Mode | Water Cooling | |
| Applicable Material | Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Graphic Format Supported | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | |
| Place of Origin | Shandong, China | Brand Name | XYZ-TECH | |
| Model Number | XJ1390 | Dimension(L*W*H) | 1.82*1.35*1.1m | |
| Certification | CE, ISO, Other, CE, ISO, BV FDA | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Factory direct sale new style wood acrylic CO2 laser engraving machine desktop laser cutting machine
Professional and high quality c02 laser cutting engraving machine:
1. Taiwan PMI square guide rails for XYZ-axis
2. sealed CO2 laser tube with 60W,80W,100W,130W,150W, we use famous RECI brand laser tube made in Beijing.
3. Leadshine stepper motor and driver
4.belt transmission, also can be optional ball screw transmission, if you need, we can produce it for you
5.laser head with red light positioning function
6. exhaust fan and air pump, so it can adsorb the smoke when you engrave and cut the materials
7.water chiller, it can recycle the water and then cool the laser tube.
8.Ruida or Leetro control system in English, with USB interface
9. knife table or honeycomb table, it's up to you, if you want to cut cloth or fabric, it's best for you to choose honeycomb table
10. We adopt RECI CO2 Quality Laser Tube with Associated laser power supply. Life-span is 10,000hours' working time, 300days warrantited.
Choice a suitable working area
Tell me the Max. size of material you want to engrave, later we can find the good working area that is suitable for you.
We have smallest size 500*300mm, also have 600*900mm,bigger size , we have 1200*800mm, 1300*900mm,1300*2500mm,1500*3000mm.etc
power
Please tell me the thickness you want to cut, or the engraving depth you need engrave, later I will know what power of laser tube is good for your job.
Applicable Materials of the cnc laser glass cutting machines:
Acrylic/ Plexiglas/ double color board/ ABS board/PVC board/ bamboo/ MDF/ wood/ paper / leather/ fabric/ wool/ rubber/ resin etc.
CNC Laser engraving Machine applicable Industries:
Advertisement( marks/ signs/ billboards/plates) bamboo & wood product/ art craft work/ ornament/ paper-cutting /cloth/ fabric/ hang bag/ glove/ garment/ leather/ embroidery/ shoemaking/ toy/ crystal/ packing & printing/ panel/ mould/ decoration/upholster and other related industries.
Technical parameters:
Machine Model | XJ-1390 |
Working Range | 1300*900mm |
Laser-type | Beijing RECI Hermetic and detached CO2 laser tube |
Laser-power | RECI Z2-90W / Z4-100W /Z6-130W for option |
Max Power | Between 300w and 1000w |
Cooling Mode | Circulating-water-cooling |
Power Adjustment | 0-100% controlling, no segment and adjusting by software |
Machine Control and Drive | Speedy DSP controlling, stepper motor |
Engraving Speed | 1200mm/s |
Cutting Speed | 500mm/s |
Repeating Location | ±0.01mm |
Minimum Character | Chinese character 1.5mm, crisscross-row 1mm |
Adjustable Up-down Distance of Laser Head | 30mm |
Working Travel Area | 1300×900mm, 900mm width with infinity material-feeding |
Working Voltage | AC 100V/220V 50Hz/60Hz |
Working Environment | Temperature: 0-45, Humidity: 5%-95%, and congeal-water removed |
Controlling Software Language | English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
Dictate Format | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, Support AutoCAD,CoreDraw direct outputting |
Main Parts for our model XJ1390 CO2 Laser cutting engraving machine:

Samples made our CNC LASER CUTTING engraving Machine:
Our company has good relations of cooperation with many substantial ship-owning companies.we can provide deasonable service charges,punctual and efficient transport services.
We started to produce Mechanical and Laser Engraving Machine in 1994. Nearly 20 years rich experience in producing saling and service ensures you high quality machine and perfect service.
Our Export Percentage up to 81%~90%. OEM Service Offered Design Service Offered Buyer Label offered.
We have business relationship with Maersk Sealand, one of the best shipping company in the world. Land, sea and air transportation covering the world to ensure you get your parcel timely.
We have R&D Production Department, Quality Control Department, and Sales &Services Department to offer you top quality machine, perfect after-sales service.

1) This is the first time I use this kind of machine, is it easy operate?
There are english manual or guide video that show how to use machine.
If there is still have any question, we can talk from phone or skype.
2) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problem.
Free after-sales service life for machine, please feel free contact us if your machine have any problem. we will give you 24hours service from phone and skype.
3) MOQ ?
Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you.
Welcome to our company personally,we are very appreciated it if you are interested in our
products.Please contact us at your convenience.Thank you very much for your reply.
