XJ 1160 High Speed Cutting Plotter Drive

Specifications

XJ 1160 high speed cutting plotter drive
1.Easy to operate with new computational method
2.High accuracy and quality. Long li



XJ 1160 high speed cutting plotter drive



Features and Specialties:



1.Front and back material feed.

2.Emergency stop and free setting original point.

3.Maximum speed of 600mm/s.

4.Cutter speed and cutter pressure memory and storage.

5.Double photoelectric reset and without any collision.

6.Perfect output and without any saw tooth at high speed.

7.Using the most advanced subdivision circuit and having low noise.

8.Using switching power supply and its operation won’t influenced by voltage change.

9.Circuit uses low power consumption and dosen’t need fan for heart radiation so as to ensure long and reliable operation.



Techinical parameters:



Model	XJ860	XJ960	XJ1160	XJ1360	XJ1660
Paper feed width	850mm	950mm	1130mm	1330mm	1660mm
Real cutting range	720mm	800m	1000mm	1200mm	1500mm
Cutting speed	0~375mm/s
Cutter pressure	0~400g
Language	HP-GL/DMPL compatible
Power supply	220v/110v  50Hz
Memory	4M
Machine stand	with
LCDce	Chinese,English
