Rabbit CW5000 CO2 Laser Machine Cooling Water Chiller

FOB Price

US$ 200 - 400 / Set

1 Set(Min. Order)

Port Qingdao Shanghai Beijing
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	new	Type	Water-Cooled
Place of Origin	Shandong, China	Brand Name	King Rabbit
Model Number	CW-5000	Voltage	100-240V
Dimension(LWH)	552843cm	Weight	26kg
Certification	CE	Warranty	one year for the machine
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Rabbit CW5000 CO2 laser machine cooling water chiller

Product Description

1. Features:

1) Convenient for installation and operation;

2) Integrated electronic control, large digital displays;

3) Single temperature, single control;

4) Low flow alarm;

5) Over heat and over low temperature alarm;

6) One-stop automatic intelligent temperature control: in different environment, user does not need to change setting due to it will automatically switch to appropriate operating temperature.

2. Specification of Laser Water Chiller CW5000 :

Model	CW-5000AG	CW-5000BG	CW-5000DG
Voltage	AC 1P 220V	AC 1P 220V	AC 1P 110V
Frequency	50Hz	60Hz	60Hz
Current	1.4-2.1A		3.5-5.6A
Compressor Power	0.295KW	0.38KW	0.305KW
Compressor Power	0.40HP	0.52HP	0.41HP
Refrigeration Capacity	2361Btu/h	2999Btu/h	2866Btu/h
	0.692KW	0.879KW	0.84KW
	595Kcal/h	756Kcal/h	722Kcal/h
Refrigerant	R-134a
Refrigerant Charge	300g	320g	280g
Precision	±0.3℃
Reducer	Capillary
Protection	Overcurrent protection for compressor, flow alarm, over temperature alarm
Pump Power	0.03KW
Inlet and Outlet	External Φ10mm brass connetor
Tank capacity	6L
Max. Lift	10M
Max. Flow	10L/min
N.W.	24kgs
G.W	27kgs
Dimensions	58x29x47cm(LxWxH)
Packing Dimensions	70x43x58cm(LxWxH)

Detailed Images

Our Services

Guarantee and After Sales Service

1.One year warranty,main parts are free of charge when problems happened during the guarantee period.

2.We provide the consumable parts at agent price when you need replacement

3.24 hours online service each day,free technical support with different languages.

4.We provide door to door technical support ,if necessary.

We offer training in our factory.

<Welcome to our factory for visiting and trainning.> (need samples provided)

Machine spare parts and repair service is also available from us.
