Laser Cutting Machine With Fast Work

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Qingdao port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Laser Type	CO2
Applicable Material	Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood	Cutting Thickness	30mm
Cutting Area	2200*1000	CNC or Not	Yes
Cooling Mode	Water Cooling	Graphic Format Supported	AI, PLT, DXF, BMP, DST, DWG
Place of Origin	Shandong, China	Brand Name	JQ
Model Number	2210	Certification	CE, Other, CE, FDA
After-sales Service Provided	Overseas service center available

Packaging Details

standard export wooden case

Product Description

Specifications

laser cutting machine with fast work
1) designed with large working area
2)four heads
3)low price&CE

laser cutting machine with fast work

Product Features

1)This machine is designed with large working area and four laser heads work together improved the efficiency in large degres

2)Could configure honey comb workable for cutting fabric,leather,rubber and other soft materiaks,and alumium knife workable for cutting acrylic,wood,and other hard metarial.

3)One design is belt&steper motor guaranteeing cutting speed and engraving accuracy,The other is ballscrew& Japanses servomotor ensuring the cuttin carfts,etc

4)The customer can choose the machine workable kind and laser power

////////////////////////////////////////////////////////////////////////////////////////

Prouct Features

Model NO.

high efficiency 4-heads wood&acrylic&die board laser engraving machine JQ2210

Laser power

60W /80W /100W perfect for engraving

Cooling system

Water cooling

Working Area

2200mm(L)*1000mm(W)

Machine Dimension

2500mm*1500mm*1300mm

Net Weight

1000kg

Driving System

stepper motor

Engraving speed

0-6000cm/min

Cutting speed

0-3600cm/min

Power Supply

220V/50Hz, 110V/60Hz

Graphic Format Supported

PLT, DXF, BMP, JPG ,AI, CDR and so on

Software Supported

Coreldraw, Photoshop, AutoCAD, Tajima

Operating Temperature

0 - 45°C

Operating Humidity

5-95%

Recommend Spare Parts

Laser tube and focus lense

Machine main parts

Water pump, air pump, exhaust fan and wind pipe, red light pointer, Knife worktable and so on.

Applicable Indusries

Clothing industry advertisement industry model industry(construction models,aviation and navigation models and wooden toys) advertising decoration arts and crafts etc

Applicable Materials

Acrylic,wood,bamboo,double-clor sheets,paper,fabric,leather etc.

Guarantee and after-sale service
1)One year guarantee for whole machine except of laser tube and lens
2)24 hours technical support by e-mail, calling or door-to-door service
3)English software, user manual and detailed Videos CD
Samples

Company Profile

Jinan JinQiang Laser CNC Equipment Co., Ltd.

Jinan JinQiang Laser CNC Equipment Co.,Ltd is located in Jinan High & New Technology Industrial Development Zone. We are committed ourselves to developing, producing and selling laser equipment. Our company supplies JQ series of laser engraving and laser cutting equipment, laser engravers and laser cutters. They are used in many fields. With high quality products and top after-sales service, we have won trust and support of customers from all over the world. Our company is guided by the market-oriented concept as well as masterful technique, and regards "good service and customers' benefits" our rules. With technical development, and many years of research, our products are improved day by day. Our philosophy is "Golden Quality, The Best Technique and Good Faith". We are trying to be a well-known company at home and abroad with the perfect and considerate after-sales service system. We welcome customers from all over the world to cooperate with us. Please feel free to contact us for further information. Selecting JQ laser the world will become yours !
