Specifications
1 with CE and FDA.2 large-area cutting in garment field
3 with water chiller and air pump
4 red dot pointer
5exported lens
Technical Performance Of JQ-1621 Laser cutting machine
Machine Model |
JQ-1621 |
Working Size |
1600*2100mm / 63in*93in (L*W) |
Laser Power |
80W/100W/150W/180W |
Laser Type |
CO2 sealed high quality, water-cooling |
Driving System |
Stepper Motor Optional: Servo Motor |
Cutting Speed |
0-40000mm/min / 0-1575in/min |
Engraving Speed |
0-70000mm/min /0-2756in/min |
Resetting Position Accuracy |
≤±0.01 |
Power Supply |
220V/50Hz, 110V/60Hz, |
Operating Temperature |
0-45°C |
Operating Humidity |
5-95% |
Min. Shaping Character |
English 1.0*1.0mm |
Operating System |
Windows 2000, Windows98, Windows XP, Vista |
Graphic Format Supported |
BMP, PLT, AI, DST, DXF |
Software Supported |
CorelDraw, Photoshop, AutoCAD, Tajima |
Machine Dimension |
2680*2300*1120mm / 106*91*44in |
Packing Dimension |
2780*2400*1300mm /109*94*51in |
Net Weight |
1200kg |
Applicable Materials
Fabrics,leather,paper,bamboo ware,acryl,glass,thin film and canvas,etc.
Guarantee and after-sale service
- Two years guarantee for whole machine except of laser tube and lens
- 24 hours technical support by e-mail, calling or door-to-door service
- English software, user manual and detailed Videos CD
samples
