Specifications
Bins and Boxes laser cutting machine1.CE& FDA certificate
2.USA mirrors and lens
3.LEADSHINE stepper motor
JQ 1614 large stencil laser cutting machine
1.Performance Features:
1). Configure high power laser tube.
2). DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.
3). Owns functions of restoring from power off, continuation on break point.
4). Transmit files directly in Coreldraw, AutoCAD,etc.
5). Adopt international linear rail, more precision.
The machine adopts CO2 laser tube and high-performance NC-controlled laser electric source, and is equipped with DSP 4.0 laser engraving and cutting software with automatic intellectual property. Its performance is stable and operation is easy
2.Specification Parameters
Model | JQ1614 |
Laser Power | 80W/100W/150W/180W |
Laser Type | sealed CO2laser tube,water-cooled,10.6um |
Work Area | 1600 X 1400 mm |
Cooling Type | Water-cooled and Protection System |
Engraving Scanning Speed | 0-60000 mm/min |
Cutting Speed | 0-1000mm/min |
Laser Output Control | 1-100% Software Setting |
Smallest Character Engraving | English: 1.0X1.0 mm |
Highest Scanning Precision | 2500DPI |
Power Supply | AC 110-220V±10%, 50-60Hz |
Operating Temperature | 0oC-45°C |
Operating Humidity | 5%-95% |
Locating Precision | ≤±0.01mm |
Supported File Format | DSTPLTBMPDXFAI |
Compatible Software | TAJIMACORELDRAWPHOTOSHOPAUTOCADAll Type of AUTOCAD Software in cloth |
Slope Engraving | 360°Slope Can Be Designed Easily |
Driving System | Stepper Electrical Motor |
Package Dimension | 2060*1650*1450mm |
Net Weight | 600KGS |
Gross Weight | 700KGS |
Optional Spare Parts | Up-down Worktable, Rotary System, Honeycomb Worktable |
Removable Spare Parts | Laser Tube and Lens |
3.Applicable Industries
Garments sampling, large width tailoring, leather industry, shoemaking decoration, furnture, advertisement, packing and printing, molding and art craft industries, etc.
4.Applicable Materials
Fabrics, leather, paper. bamboo ware, acrylic, glass, films and canvas, etc.
5.The warranty after-sale service
1).CE and FDA certificate,the machines are produced according to standard.
2).Two years quality guarantee for whole machineexcept of laser tube and lens ;
3).We have excellent egineers speaking English,they can go to your country to solve your questions of machine you can't solve;
4).The machines delivery is quickly,delivery time is short.
5).24 hours technical support by e-mail, calling or door-to-door service
6).English software, user manual and detailed Videos CD
WELCOME TO BECOME OUR AGENT.WELCOEM TO JOIN JQ-LASER.
