Specifications
Jinqiang Cutting deep materials laser cutting equipment1.Best quality machine parts
2.Easy to operate
3.Good sale service
Jinqiang Cutting deep materials laser cutting equipment
Performance Features:
1.Configure high power laser tube.
2.DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.
3.Owns functions of restoring from power off, continuation on break point.
4.Transmit files directly in Coreldraw, AutoCAD,etc.
5.Adopt international linear rail, more precision.
Parameters
Model |
JQ-1312 |
Laser Power |
150W |
Laser Type |
sealed CO2laser tube,water-cooled,10.6um |
Work Area |
1300X1200mm |
Cooling Type |
Water-cooled and Protection System |
Engraving Scanning Speed |
0-60000 mm/min |
Cutting Speed |
0-15000mm/min |
Laser Output Control |
1-100% Software Setting |
Smallest Character Engraving |
English: 1.0X1.0 mm |
Highest Scanning Precision |
2500DPI |
Power Supply |
AC 110-220V±10%, 50-60Hz |
Operating Temperature |
0°-45°C |
Operating Humidity |
5%-95% |
Locating Precision |
≤±0.01mm |
Supported File Format |
DSTPLTBMPDXFAI |
Compatible Software |
TAJIMACORELDRAWPHOTOSHOPAUTOCADAll Type of AUTOCAD Software in cloth |
Slope Engraving |
360°Slope Can Be Designed Easily |
Driving System |
Stepper Electrical Motor |
Package Dimension |
2160*1810*1400mm |
Net Weight |
600KGS |
Gross Weight |
650KGS |
Optional Spare Parts |
Up-down Worktable, Rotary System, Honeycomb Worktable |
Removable Spare Parts |
Laser Tube and Lens |
Applicable Industries
Garments sampling, large width tailoring, leather industry, shoemaking decoration, furnture, advertisement, packing and printing, molding and art craft industries, etc.
Applicable Materials
Fabrics, ather, paper. bamboo ware, acrylic, glass, films and canvas, wood, porcelain, double colour boards,acryli,cloth,etc.
