Specifications
furniture laser cutting mahchine1)working area:1200*2400mm
2)support AutoCad, CorelDraw,PhotoShop
3)80w/100w/130w
4)CE
Selecting JQ Laser,the world will become yours!!
JQ-1224 furniture laser cutting machinePerformance Features:
1. Configure high power laser tube.
2. DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.
3. Owns functions of restoring from power off, continuation on break point.
4. Transmit files directly in Coreldraw, AutoCAD,etc.
5. Adopt international linear rail, more precision.
Machine Parameters:
Model | JQ-1224 furniture laser cutting machine |
Laser Power | 80W/130W |
Laser Type | CO2 sealed, glass laser tube, water cooling |
Work Area | 1200 X 2400 mm |
Cooling Type | Water-cooled and Protection System |
Engraving Scanning Speed | 0-60000 mm/min |
Cutting Speed | 0-15000mm/min |
Laser Output Control | 1-100% Software Setting |
Smallest Character Engraving | English: 1.0X1.0 mm |
Highest Scanning Precision | 2500DPI |
Power Supply | AC 110-220V±10%, 50-60Hz |
Operating Temperature | 0°-45°C |
Operating Humidity | 5%-95% |
Locating Precision | ≤±0.01mm |
Supported File Format | DSTPLTBMPDXFAI |
Compatible Software | TAJIMACORELDRAWPHOTOSHOPAUTOCADAll Type of AUTOCAD Software in cloth |
Slope Engraving | 360°Slope Can Be Designed Easily |
Driving System | Stepper Electrical Motor |
Package Dimension | 3060X2360X1400 mm |
Net Weight | 600KGS |
Gross Weight | 650KGS |
Optional Spare Parts | Up-down Worktable, Rotary System, Honeycomb Worktable |
Removable Spare Parts | Laser Tube and Lens |
Applicable Industries:Garments sampling, large width tailoring, leather industry, shoemaking
decoration, advertisement, etc.
Applicable Materials:leather, bamboo ware, acrylic, acryl, cloth, etc.
Our laser machines could be customzied according to your special requirements such as the dimension of the cutting area, the laser power,the color of the machine and so on.
