laser etching machine to etch photos on granite headstones
- 300 Set / Sets per Month
- qingdao
- T/T Credit Card
You May Like
-
CE FDA high accuracy granite marble stone craving equipment
-
stone laser engraving machine
-
Split type granite laser engraving machine with 1000*600mm working size
-
China 60W portable laser machine/stone image laser engraving machine
-
best selling dismountable stone laser engraving machine price JQ1060
-
surface working CO2 laser granite Stone Engraving Machine for sale
Product Details
Condition | New | Laser Type | CO2 | |
Engraving Area | 1300*2500mm | Engraving Speed | 0-70000Mm/min (0-2756 inch/min) | |
CNC or Not | Yes | Cooling Mode | Water Cooling | |
Applicable Material | Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Graphic Format Supported | AI, BMP, DST, DXF, PLT | |
Place of Origin | Shandong, China | Brand Name | JQ | |
Model Number | JQ-1325 marble/ granite/gravestone/tombstone laser engraving machine | Dimension(L*W*H) | 3350*2150*1250mm | |
Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Standard export plywood case.
Product Description
laser etching machine to etch photos on granite headstones
1.Features of JQ-1325 marble/ gravestone/tombstone engraving laser machine
a.The machine is equipped with hydraulic worktable, which can hold 4 to 10 tons material.
b.The worktable is able to move up and down at the Z-Axis with 10 tons stones easily, which solves the thickness problem successfully.
c.The up-down worktable can adjust the heights in the four directions separately to ensure the flat surface of the stones.
d.The machine body is movable, which can process infinitely long material easily.
2.Parameter of JQ-1325 marble/ granite/gravestone/tombstone laser engraving machine
Machine Model | JQ1325 glass laser engraving machine |
Working Size | 1300mm*2500mm 51in*98in (L*W) |
Laser Power | 100W/150W/180W |
Laser Type | CO2 sealed high quality, water-cooling |
Driving System | Stepper motor |
Engraving Speed | 0-70000Mm/min (0-2756 inch/min) |
Resetting Position Accuracy | ≤±0.01 |
Power Supply | 220V/50Hz, 110V/60Hz, |
Operating Temperature | 0-45°C |
Operating Humidity | 5-95% |
Min. Shaping Character | English 1.0*1.0mm |
Operating System | PCI OR USB (DSP 6535) |
Graphic Format Supported | BMP, PLT, AI, DST, DXF |
Software Supported | Coreldraw, Photoshop, AutoCAD, Tajima |
Machine Dimension | 3350*2150*1250mm 131*84*49in |
Packing Dimension | 3450*2250*1350mm 134*87*52inch |
Net Weight | 2000kgs |
3.Applicable materials: wood ,synthetic material, acrylic, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass ,marble,granite and other nonmetal materials, etc.
4. Guarantee and after-sale service
Two year guarantee for whole machine except of laser tube and lens
24 hours technical support by e-mail, calling or door-to-door service
English software, user manual and detailed Videos CD
As a professional manufacturer we can supply different model according
to your different materials. So you also can tell me
1. What materials do you need to process? non metal material?
2. What is the size and thickness of each materials you want to cut?
3. What is your business scope? Are you an end user or distributor?
We will be very happy to help you in any way we can.
JQ FAQ:
1.Q: Are you a factory or trading company?
A:We are a manufacturer with export license
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Jinan City, Shandong Province, China, about 1 hours from
Beijing, 2 hours from Shanghai and 2.5 hours from Guangzhou.All our clients, from home or
abroad, are warmly welcome to visit us!
3.Q: Can you do OEM?A: Yes, we can do OEM products.
It's no problem.
4.Q:How can I get some samples?
A:1,We are honored to offer you samples. New clients are expected to pay for the courier
cost, the samples are free for you, this charge will be deducted from the payment for formal
order.
2,Regarding the courier cost: you can arrange a RPI (remote pick-up) service upon Fedex,
UPS, DHL, TNT, etc. to have the samples collected; or inform us your DHL collection account.Then you can pay the freight direct to your local carrier company.
5.Q:How does your factory do regarding quality control?
A:"Quality is priority? JQ people always attach great importance to quality controlling from the very beginning to the very end:
1).All raw material we used are environmental-friendly;
2).Skillful workers care every details in handling the producing and packing processes;
3).Quality Control Department specially responsible for quality checking in each process.
If you are interest in our products or our services, please contact us, you will get the best reliable products in reasonable prices.
My skype: jqlaser31
Whatsapp: 0086 15550002101
Company Profile

Jinan JinQiang Laser CNC Equipment Co.,Ltd is located in Jinan High & New Technology Industrial Development Zone. We are committed ourselves to developing, producing and selling laser equipment. Our company supplies JQ series of laser engraving and laser cutting equipment, laser engravers and laser cutters. They are used in many fields. With high quality products and top after-sales service, we have won trust and support of customers from all over the world. Our company is guided by the market-oriented concept as well as masterful technique, and regards "good service and customers' benefits" our rules. With technical development, and many years of research, our products are improved day by day. Our philosophy is "Golden Quality, The Best Technique and Good Faith". We are trying to be a well-known company at home and abroad with the perfect and considerate after-sales service system. We welcome customers from all over the world to cooperate with us. Please feel free to contact us for further information. Selecting JQ laser the world will become yours !
