Home > Products > Stone Marble laser engraving machine > China laser engraving machine JQ1060 split stone 3D laser carver
China laser engraving machine JQ1060 split stone 3D laser carver
- Qingdao port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Laser Type | CO2 | |
| Engraving Area | 1000*600mm | Engraving Speed | 0-60000mm/min | |
| CNC or Not | Yes | Cooling Mode | Water Cooling | |
| Applicable Material | Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Graphic Format Supported | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | |
| Place of Origin | Shandong, China | Brand Name | jq laser | |
| Model Number | 1060 | Dimension(L*W*H) | 1000*600 | |
| Certification | CE, SGS, Other, CE, SGS, FDA | After-sales Service Provided | Engineers available to service machinery overseas |
First we used preservative film packaging machine, second air cushion film packaging machine, third standard exported wooden case.
packaging dimension: 2.02*1.88*1.4m
Product Description
China laser engraving machine JQ1060 split stone 3D laser carver
Performance Features
1.Configure higher power laser tube.
2.DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.
3.Owns functions of restoring from power off, continuation on break point.
4.Transmit files directly in CorelDraw, AutoCAD ,etc.
5.Adopt international linear rail, more precision.
Techincal Parameter
Laser cutting Bed Technical Specifications | |
Item / Model | JQ-1060 |
Cutting area | 1000x 600mm |
Laser power | 25w/30w/45w/60w |
Laser type | CO2 sealed laser tube,water-cooled,10.6um |
Engraving speed | 0-60000mm/min |
Laser Output | 1-100%software setting |
Resetting positioning accuracy | ≤±0.01mm |
Power supply | AC 110 - 220V ± 10%, 50 - 60Hz |
Operating temperature | 0 - 45°C |
Operating humidity | 5 - 95% |
Min. shaping character | English 1.0mm x 1.0mm |
Graphic format supported | BMP, PLT, DST, DXF, AI |
Software supported | Tajima,CorelDraw, PhotoShop, AutoCAD |
Driving system | Stepper |
Cooling mode | Water-cooling and protection system |
Equipment Dimensions | 3080x2000x1120mm |
Net Weight: | 1100kg |
Optional Spare Parts | Up-down clump, Rotary System, Honeycomb table |
Recommended Spare Parts | Laser Tube and Lens |
Application Field
Applicable materials:
wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials,etc.
Applicable industries:
advertisement, gift, shoes, toys, computers, garments, model cutting, building, packaging, paper industry,etc.
Samples
Packaging Detail: stable, strong and CE standard export plywood cases.
Delivery Detail: within 7 working days
2 years warranty for the whole machine, 9 months for 150w tube, Lifetime Maintenance.
1. Perfect after-sale service, our engineer will provide the whole day online, on site service.
2. Professional engineer will provide one site installation, training of the operation of the machine, how to use the software, machine maintenance, ensure that customers can use the machine properly.
3. Within warranty period time of the machine, machine quality causes any damage , JQ laser company will responsible replacement parts and service for free , except regular consumables ( such as optical lenses, nozzles ) and belongs to the user irregularities operating .
4. Online or telephone communication can not solve the problem, JQ engineer will provide door to door service, solve problem in time for customer.
5. The company will pay a return visit work non-scheduled, in order to have a assessment for our every after-sell service staff, make sure our service more and more better.
Jinan JinQiang Laser CNC Equipment Co.,Ltd, located in the beautiful “Spring City” Jinan, was established in 2004. It is one of the most influential specialized manufacturers and suppliers of laser equipment in China. JQ as the best laser machine manufacturer in China, has cooperated with many companies from domestic and abroad.
With powerful R&D strength, being market-oriented, many years of experiment and practice, JQ LASER has developed a new advanced solid laser cutting system with large format and gantry structure. And JQ has been in many fairs in domestic and abroad.
Q1.how to get the most suitable machine and best price?
please tell the material you want to working on ?
How to working on it ? Engraving ? Cutting ? Or other ?
What’s the MAX size of these material ?( length ? Width ? Thickness ?)
Q2.If we don't know how to use the machine,can you teach us?
Yes,we will, if you come to China,we will offer you free training until you can use machine freely.An
d if you are busy ,we will have the special engineer to your country,but you need to bear some fee,like tickets and hotel and meal.
Q3.How about your after-sales service?
we offer you 24 hours service phone,skype,WhatsApp or MSN.
Q4. Quality Control
The whole production procedure will be under regular inspection and strict quality control. The
complete machine will be tested to make sure they can work very well before being out of factory.
The testing video and pictures will be available before delivery.
Thanks for reading!
Any questions plz feel free to contact with me*
You will get response in 12 h.
Valerie
Skype: jqlaser9
WhatsApp:0086 18253185013
Company Profile
Jinan JinQiang Laser CNC Equipment Co.,Ltd is located in Jinan High & New Technology Industrial Development Zone. We are committed ourselves to developing, producing and selling laser equipment. Our company supplies JQ series of laser engraving and laser cutting equipment, laser engravers and laser cutters. They are used in many fields. With high quality products and top after-sales service, we have won trust and support of customers from all over the world. Our company is guided by the market-oriented concept as well as masterful technique, and regards "good service and customers' benefits" our rules. With technical development, and many years of research, our products are improved day by day. Our philosophy is "Golden Quality, The Best Technique and Good Faith". We are trying to be a well-known company at home and abroad with the perfect and considerate after-sales service system. We welcome customers from all over the world to cooperate with us. Please feel free to contact us for further information. Selecting JQ laser the world will become yours !
