PVC Acrylic Board Co2 Laser Cutting Machine With Most Popular

Name: PVC Acrylic Board Co2 Laser Cutting Machine With Most Popular
Brand: JQ laser
Availability: InStock

FOB Price

US$ 6,000 - 15,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Laser Type	CO2
Applicable Material	Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood	Cutting Thickness	30mm
Cutting Area	1300*2500	Cutting Speed	0-30000mm/min
CNC or Not	Yes	Cooling Mode	Water Cooling
Control Software	leetro6565	Graphic Format Supported	AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Place of Origin	Shandong, China	Brand Name	JQ laser
Model Number	JQ-1325	Certification	CE, SGS, Other, CE, SGS, FDA
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

plywood case in container

Product Description

PVC acrylic board co2 laser cutting machine with most popular

Product Features

1.Configure higher power laser tube.
2.DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.
3.Owns functions of restoring from power off, continuation on break point.
4.Transmit files directly in CorelDraw, AutoCAD etc.
5.Adopt international linear rail, more precision.

Product Parameter

Machine Model	JQ1325 glass laser engraving machine
Working Size	1300mm2500mm 51in98in (L*W)
Laser Power	80W/100W/150W
Laser Type	CO2 sealed high quality, water-cooling
Driving System	Stepper motor
Cutting Speed	0-40000mm/min (0-1575 inch/min)
Engraving Speed	0-70000Mm/min (0-2756 inch/min)
Resetting Position Accuracy	≤±0.01
Power Supply	220V/50Hz, 110V/60Hz,
Operating Temperature	0-45°C
Operating Humidity	5-95%
Min. Shaping Character	English 1.0*1.0mm
Operating System	PCI OR USB (DSP 6535)
Graphic Format Supported	BMP, PLT, AI, DST, DXF
Software Supported	Coreldraw, Photoshop, AutoCAD, Tajima
Machine Dimension	335021501250mm 1318449in
Packing Dimension	345022501350mm 1348752inch
Net Weight	1100kgs

Applicable Industries

Garments sampling,large width tailoring,leather industry,shoemaking decoration,furnture,advertisement,packing and printing,molding and art craft industries,etc.

Applicable Materials

Non-metal materials such as Fabrics,leather,paper,acrylic,glass,films and

canvas,etc.

Guarantee and after-sale service
1)two years guarantee for whole machine except of laser tube and lens
2)24 hours technical support by e-mail, calling or door-to-door service
3)English software, user manual and detailed Videos CD

Samples

Company Profile

Jinan JinQiang Laser CNC Equipment Co., Ltd.

Jinan JinQiang Laser CNC Equipment Co.,Ltd is located in Jinan High & New Technology Industrial Development Zone. We are committed ourselves to developing, producing and selling laser equipment. Our company supplies JQ series of laser engraving and laser cutting equipment, laser engravers and laser cutters. They are used in many fields. With high quality products and top after-sales service, we have won trust and support of customers from all over the world. Our company is guided by the market-oriented concept as well as masterful technique, and regards "good service and customers' benefits" our rules. With technical development, and many years of research, our products are improved day by day. Our philosophy is "Golden Quality, The Best Technique and Good Faith". We are trying to be a well-known company at home and abroad with the perfect and considerate after-sales service system. We welcome customers from all over the world to cooperate with us. Please feel free to contact us for further information. Selecting JQ laser the world will become yours !
