nylon fabric laser cutting machine
Laser cutting and engraving is a new processing method. it has many advantages like high precision, fast application,stable quality,material saving,good reliability etc.Nowadays, it's becoming more and more popular in the fabric field
Since the laser machine will cut the materials according to the design of the CAD file,if the designer likes to make any revision of the design, he only need to revise the CAD files directly.Then he can see the final result quickly with the help of a JQ Laser laser system.
Features of cloth laser cutting machine:
a. The rolls of the machine are able to roll up the large material automatically. Improved the working efficiency greatly.
b. Usually, the laser tube is installed above the machine body. This machine’s laser tube is installed in the machine body so it is more secure.
c. There are two control panels on the machine. The users could control the machine at both sides.
d. DSP control system and moderate using environment.
e. Some parts are imported and more durable like the mirrors and lens, rails, motors. etc.
f. Scientific ventilation equipments, high power exhaust fan and strong honeycomb worktable play a vacuum adsorption, which can make the soft material very flat.
Technical Performance Of JQ-1630
Machine Model | JQ-1630 |
Working Size | 160*300cm |
Laser Power | 80W/100W/150W |
Laser Type | CO2 sealed high quality, water-cooling |
Driving System | 3 phase Stepping motor |
Cutting Speed | 0-40000mm/min / 0-1575in/min |
Engraving Speed | 0-70000mm/min / 0-2756in/min |
Resetting Position Accuracy | ≤±0.01 |
Power Supply | 220V/50Hz, 110V/60Hz, |
Operating Temperature | 0-45°C |
Operating Humidity | 5-95% |
Min. Shaping Character | English 1.0*1.0mm |
Operating System | PCI OR USB (MPC 6535) |
Graphic Format Supported | BMP, PLT, AI, DST, DXF |
Software Supported | Coreldraw, Photoshop, AutoCAD, Tajima |
Machine Dimension | 350cm*230cm*150cm (L*W*H) 138in*90in*59in |
Packing Dimension | 370cm*250cm*170cm(L*W*H) 145in*98in*67in |
Net Weight | 1300 kg |
Applicable Material
Cuttingmaterial:Cloth,fabric,leather,woolen,paper,embroider,wood,acrylic,organic glass, rubber, plastic, compound material and other non-metal materials,etc
Engraving material: Cloth, fabric, leather, woolen, paper, embroider wood, acrylic, organic glass, rubber, plastic, compound material and other non-metal materials,etc
Guarantee and after-sale service
- Two year guarantee for whole machine except of laser tube and lens
- 24 hours technical support by e-mail, calling or door-to-door service
- English software, user manual and detailed Videos CD
samples
All these products are designed and developed by ourselves. We assure that we can provide goods with competitive price, high quality and best service. Looking forward to building a good relation in the furture.
DIY Customer bought JQ1630 do DIY fabric toys on Taobao
All these products are designed and developed by ourselves. We assure that we can provide goods with competitive price, high quality and best service. Looking forward to building a good relation in the future.
