Specifications
Yaskawa servo systemGeneva type library
Taiwan SYNTEC controlling system
Matrix vacuum table
one spindle wood working ATC cnc center with gantry moving
Performance Feature:
1.Integral welding body,high inflexibility structure design,material stress analysis&forming by heat treatment
,avoid deformation.
2.Transmission part adopts high pression helical rack,THK linear rail from Japan,supplement with Japan
Yaskawa servo system and Taiwan professional deceleration device,ensure machine running smoothly
in high speed,high precision,low noise.
3.Equipped with professional vacuum system,adopt integral adsorption base,with the high strength
engineering-plastics surface,one-time forming,adopt high-power professional vacuum pump,strong adsorption capacity.
4.Imported high power spindle from Italy,low sway in axial,strong cutting force,long lifetime,low noise.with
imported Geneva Type library of&8pcs tool,high efficiency.
5. Industrial control system,professional electronic parts,perfect function,stable performance,strong
compatibility of software.
Technical data:
Item |
MG1325A |
MG1630A |
MG2030A |
Working size |
1300×2500×210mm |
1600×3000×210mm |
2000×3000×210mm |
Table size |
1220×2440mm |
1530×2940mm |
1930×2940mm |
Max.travel speed |
X-30m/min.Yaxis-30m/min.Zaxis-20m/min |
||
transmitting |
X.Y-high accuracy helical gear.Z-rolling ball screw |
||
Servo type |
Japan Panasonic(Yaskawa is optional) |
||
Spindle type |
Italy 10KW ATC spindle motor |
||
Spindle rev. |
18000-24000rpm |
||
Vacuum table |
Matrix vacuum table |
||
Pump type |
Moporo(Germany Becker is optional) |
||
Tool type |
Geneva Type |
||
Tool magazine |
8pcs(10pcs,12pcs is optional) |
||
Controlling system |
SYNTEC(OSAI is optional) |
||
Voltage |
AC38V/3PH/50HZ |
||
Machine size |
2200×3100×2000mm |
2500×3600×2000mm |
2900×3600×2000mm |
weight |
2100KG |
2900KG |
3400KG |
