Specifications
YASKAWA servo system cnc machineheavy machine body with drill
THK Japan linear rail
CE,ISO
woodworking cnc
NEWEST China SUDA on sale woodworking cnc cnc e for making furniture
HG model woodworing cnc main data :
Item | HG1325 | HG1630 | HG2030/40 |
Working size | 1650*2750*280MM | 1950*3300*280MM | 2350*4300*280MM |
Table size | 1220*2440mm | 1530*2940mm | 1830*3800/3700mm |
Max.travel speed | X axis-30m/min, Y axis-30m/min Z axis -20m/min | ||
Transmitting | X,Y- high accuracy helical gear ,Z-rolling ball screw | ||
Servo type | Japan YASKAWA | ||
Spindle | Italy 10KW ATC spindle motor | ||
Spindle Rev. | 18000-24000rpm | ||
Gang drill | Vertical -7 pcs drilling , X,Y axis each has one horizonal drilling | ||
Vacuum table | Matrix vacuum table | ||
Pump type | China pump or Germany pump is optional | ||
Tool type | Geneva type | ||
Tool magazine | Standard 8pcs(10pcs,12pcs is optional) | ||
Controlling system | SYNTEC(OSAI is optional) | ||
Power supply | 380V/3PH/50HZ | ||
Machine size | 3500*2600*2000mm | 4000*2900*2000 | 5000*3300*200mm |
Weight | 2200kg | 2950kg | 3600kg |
HG model woodworking cnc Application
Applicable to process kinds of plate material, such as MDF, shaving board, blockboard, acrylic, PVC, hibiscus board,
engineering plastic, epoxy resin, wood, artificial stone and other materials, widely used in furniture, bathroom cabinet,
cabinets and other industries, especially in paint-free door and wood industry, can finish procedure of engraving, drilling and cutting in one step.
HG model woodworking cnc samples :
