Help CenterSuda CNC Router Cnc Router Cnc 3d Wood Carving Machine-- SG1325
Related Products
-
Suda Cnc Machine/ Cnc Router/ Engraver( With Auto Tool Change Function) SG1325HNegotiableMOQ: 1 Set -
SUDA High Performance CNC MACHINE CENTER Auto-changing Tools Cnc Hobby---SG1325HNegotiableMOQ: 1 Set
-
SUDA ATC CNC ROUTER-SG1325H ModleNegotiableMOQ: 1 Set
-
HEFEI SELL SUDA Newest ATC CNC Router--SG1325HUS$ 28,911 - 38,900MOQ: 1 Set
-
SUDA CNC MACHINE CENTER -SG1325H With ACT FunctionNegotiableMOQ: 1 Unit
Specifications
Split keyboard control,THk linear rail from Japan,
Italy high power ATC spindle motor,
Circular auto tool change system.
ce
Common Features:
*Integral cast-iron frame ,aging treatment ,much solid and rigidity.
*Import high speed ,mute rolling ball screw transmitting system,ensure processing in high
accuracy,and the running speed up to 50m/min .
*Configured with industrial DSP controlling system from Taiwan,intelligent
module,processing is more user friendly,more functions can meet your various requirement.
*Import Italy spindle motor ,big power,high efficiency,long life time using.Complete
processing complicate working pieces easilly.
*Automatic oil lubricating system,easy maintenance,prolong lifetime of transmitting parts.
*Support HPGL and G-code dictate format,complete with internationl CAD/CAM software like
Castmate/UG/Proe etc.
(H Model upgrated to imported controlling system,big power ATC system,high speed AC servo system.)
Technical Data:
Model |
SG1325H |
SG1630H |
Working Size |
1300*2500*300mm |
1550*3000*300mm |
Spindle Motor |
Italy ATC 7.5kw Spindle Motor Cooled By Air |
|
Motion Speed |
50000mm/min |
|
Spindle Rotation Speed |
0~18000RPM |
|
Tools |
Ø3.175mm, ø4mm ø6mm, ø12.7mm (OPTIONAL) |
|
Transmitting System |
X,Y,Z industrial rolling ball screw from Germany |
|
Dictate Format |
HPGL, G-CODE |
|
Resolution |
0.005mm |
|
Tool Change Mode |
Circular tool change |
|
Tool Magazine Capacity |
8pcs tools, 10,12pcs tools (optional) |
|
Tool Change Time in Between |
8 seconds |
|
Controlling System |
Syntech Controller, LNC Controller (Optional) |
|
Dust Collecting System (optional)
Vacuum System (optional)
Germany Becker Vacuum Pump (optional)
more power spindle motor can be mounted according to your requirement
can produce any size SG Series CNC Router for customers special requirement
(Note:Any changes of technical parameters without notice )
Application:
Strong function,easy operation,durable,liable and economy,stable structure ,applicable to
process various wooden products,like solid wood furniture and solid wood door ,decorative
panel,computer desk,office furniture,sign plates,acrylic cutting,vacuum plastc moulds,as
well as many metal and non-metal materials such as iron,copper,aluminum plates etc.
