MOPA Fiber Laser Device
Product Introduction
The MOPA fiber laser can maintain the peak power at the same level for different pulse repetition frequency. Compared with conventional solid state lasers,the MOPA fiber lasers with higher slope efficiency is more compact and easy to carry, enables higher beam quality of the laser output.It has advantage in high-speed marking application.
Application Fields
It’s widely applied for fiber laser markers.
Technical Parameters
Technical parameter | 20W | 30W | 20W | 20W | 30W |
Output fiber length | 2m | 2m | 2m | 2m | 2m |
Nominal Average Output Power | >20W | >30W | >20W | >20W | >30W |
Maximum Pulse Energy | 0.66mJ | 1.2mJ | 0.4mJ | 0.45mJ | 0.9mJ |
Full Power Repetition Rate Range(kHz) | 30~400 | 25~400 | 50~1000 | 40~1000 | 31~1000 |
Pulse Repetition Rate Range(kHz) | 1~400 | 1~400 | 1~1000 | 1~1000 | 1~1000 |
Pulse Duration | 200ns | 200ns | 6~200ns | 2~200ns | 2~200ns |
Longtime Average Power Stability | <5% | <5% | <5% | <5% | <5% |
Cooling Method | Air cooling | Air cooling | Air cooling | Air Cooling | Air cooling |
Power Consumption | <120V | <140V | <120V | <120V | <140V |
Central Emission Wavelength | 1064nm | 1064nm | 1064nm | 1064nm | 1064nm |
Emission Bandwidth | <5nm | <5nm | <5nm | <5nm | <5nm |
Polarization | Random | Random | Random | Random | Random |
Output Beam Diameter | 7mm | 6mm | 7mm | 7mm | 7mm |
Output Power Tuning Range(℃) | 0~100 | 0~100 | 0~100 | 0~100 | 0~100 |
Operation Temperature(℃) | 0~40 | 0~40 | 0~40 | 0~40 | 0~40 |
Samples Images
Remark
1. Payment Terms: 100% T/T in advance before delivery.
2. Delivery Method: By sea or by Express DHL/ Fedex.
3. Packing: Compound wooden cases comply with international exporting standard.
4. Warranty: 1year
