MAX MFP Pulsed Fiber Laser Source10W 20W 30W

Perfect Laser (Wuhan) Co., Ltd.

US$ 2,700 - 3,200 MOQ: 1 Set

Key Specifications

Condition:

New

Laser Type:

Fiber Laser

CNC or Not:

Yes

Payment & Shipping

Payment Methods:

Port of Shipment:

WuHan

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Laser Type Fiber Laser

CNC or Not Yes

Cooling Mode Air Cooling

Control Software EZCAD

Graphic Format Supported AI, BMP, DST, DWG, DXF, DXP, LAS, PLT

Working Accuracy 99.99%

Place of Origin Hubei, China

Brand Name Max

Model Number MFP

Power(W) 10W 20W 30W

Certification CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

MAX Pulsed Fiber Laser Source

10W-30W

Product Introduction

Pulsed fiber lasers source are functional and durable with low energy consumption .It’s advantages

likes compact structure,stand-alone and easy to use make it can be integrate to user's device directly.

Application Fields

It’s widely used for marking in low reflective materials(such as plastic,wood,paper) directly and some low reflective metal.

Technical Parameters

Technical parameter	standard type			economical type
Technical parameter	10W	20W	30W	20W	30W
Central wavelength(nm)	1055~1070	1055~1070	1055~1070	1055~1070	1055~1070
Polarization	random	random	random	random	random
Nominal average output power (W)	9.5~10.5	19.5~20.5	29.5~31	18~19.5	25.5~27.5
pulse energy(mJ)	0.5~0.6	0.8~1	0.8~1	0.7~0.8	0.8~1
Typical beam quality(M2)	<1.4	<1.8	<1.8	<1.8	<1.8
Beam diameter(mm)	6~8	6~9	6~9	6~9	6~9
Pulse repetition rate(kHz)	22 - 80	22 - 80	22 - 80	22 - 80	22 - 80
Power tunable range(%)	0~100	0~100	0~100	0~100	0~100
Output fiber length(m)	1.9~3	1.9~3	1.9~3	1.9~3	1.9~3
Cooling	air cooling	air cooling	air cooling	air cooling	air cooling
Laser module Dimension (mm)	28721595	28721595	260122347	28721595	28721595
Working temperature(℃)	0~42	0~42	0~42	0~42	0~42
Operation Humidity	10%~95%	10%~95%	10%~95%	10%~95%	10%~95%
Storing temperature(℃)	-10~60	-10~60	-10~60	-10~60	-10~60
