lace-up hoisting grip for 1-5/8" in coaxial cable
duct
Hoisting grips are used widely in the telecom infrastructure installation, it is designed for hoisting or supporting coaxial, hybrid cable or fiber cable.
Normally grips are used at intervals of 200 feet along the transmission line. For transmission lines whose length exceeds 200 feet, the hoisting grip should be left on the cable and tied off to the tower or other support structure so that the weight of the cable is supported by the grips and not by the cable hangers.
Our hoisting grips are made of high quality SS304 wire, and now we can supply open weave type and closed weave type according to the specific request.
2.Features & specs
| Product line | Cable grips |
| Product type | Lace-up hoisting grips |
| For cable type | coaxial, elliptical waveguide hybrid (FiberFeed, Hybriflex) or fiber cable |
| Size | 1/4, 3/8, 1/2, 5/8, 7/8, 1-1/4, 1-5/8, 2-1/4, 3, 4, 5 in or any other sizes |
| Number of cables | 1 cable |
| Material | Stainless steel 304 wire |
| Part number | Description |
|---|---|
| HG14L | Lace up hoisting grips for 1/4″ cable,min diameter 6mm |
| HG38L | Lace up hoisting grips for 3/8″ cable,min diameter 8.38mm |
| HG12L | Lace up hoisting grips for 1/2″ cable,min diameter 12.7mm |
| HG58L | Lace up hoisting grips for 5/8″ cable,min diameter 19mm |
| HG78L | Lace up hoisting grips for 7/8″ cable,min diameter 25.4mm |
| HG114L | Lace up hoisting grips for 1-1/4″ cable,min diameter 31.75mm |
| HG158L | Lace up hoisting grips for 1-5/8″ cable,min diameter 45mm |
| HG214L | Lace up hoisting grips for 2-1/4″ cable,min diameter 50mm |
| HG3L | Lace up hoisting grips for 3 in cable |
Lace-up hoisting grips provide an effective means for hoisting coax and elliptical waveguide into position and can be utilized to provide additional support once in place. The lace-up design allows the hoisting grip to be attached even when the run has been connectorized and facilitates easy positioning at 200 (61m) increments on long coax runs.
5/8" in coaxial cable lace-up Hoisting grip for following outdoor cable;
3.application
1, Telecom cable
2, Fiber cable
3,Coaxial cable
4, Feeder cable
5, Hybrid cable
6, Corrugated cable
7, Smooth cable
8, Braid cable
4.packing
| Packaging Details: | lace-up hoisting grip will be packed with standard export carton & pallets |
|---|---|
| Delivery Detail: | lace-up hoisting grip lead time will be 5-10 working days |
5.Factory photo
6.Company Certification
8.Test equipment & report
Get more detail on our website
