GDJ Series Oil Type Transformer, AC DC Hipot Tester

GDJ Series Oil Type Transformer, AC DC Hipot Tester thumbnail-1
GDJ Series Oil Type Transformer, AC DC Hipot Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GDJ
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GDJ

Introduction:

1. GDJ Series Oil Type Transformer, AC DC Hipot Tester is small in volume, light in weight, with compact structure and multiple function, general-purpose and easy to use.
2. Applies to the test of frequency or insulating intensity under DC ,HV for all kinds of HV electric equipments, components, insulated material in electric system, industrial and mining enterprises, traffic , post and telecommunications, science institute, etc.

Features:
1. Good material , reliable quality, good stability.
2. Wide voltage range, small PD.
3. Use new insulating material, small in volume, light in weight.


GDJ Models For Option：

ModelCapacityMax.Output voltageOutput currentLV inputRatioTemp. ℃ (30 Min)
(KVA)(KV)(mA))voltage(V)current(A)
GDJ-3/103103002001550010
GDJ-6/106106002003050010
GDJ-40/80408050040010050010
GDJ-20/5020504004005050010
GDJ-30/5030506004007550010
GDJ-5/10051005020025100010
GDJ-10/1001010010020050100010
GDJ-20/1002010020040050100010
GDJ-30/1003010030040075100010
GDJ-20/1502015013340050150010
GDJ-30/1503015020040075150010
GDJ-50/15050150333400125150010
GDJ-50/20050200250400125100010
GDJ-100/200100200500400250200010
GDJ-150/200150200750400395200010
GDJ-50/30050300170400125300010
GDJ-100/300100300333400250300010
Notes: Non-standard parameter or parameters not in the table please contact us to confirm .
