GDYJ-502 100kV Insulating Oil Breakdown Voltage BDV Tester

GDYJ-502 100kV Insulating Oil Breakdown Voltage BDV Tester thumbnail-1
GDYJ-502 100kV Insulating Oil Breakdown Voltage BDV Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GDYJ-502
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GDYJ-502

Introduction:

1. It is developed according to the national standard IEC156 Insulating Oil Dielectric Strength Testing Method .

2. LCD screen can display test pr℃edure and test result.

3. All the human interaction operations complete by the rotating mouse .

4. It is very easy for customers to measure the breakdown voltage of all kinds of oil by GDYJ-502 Oil Breakdown Voltage Tester.

5. You can print the test result by the micro printer internal the tester. Of course, you can upload the test data to PC from RS232 for data analyzing.

6. The special circuit design makes the tester has a good performance at stability and anti-noise.


Features:

1. Breakdown test of user-defined

2. Proof test

3. IEC156/IS6792/BS5874/

4. ASTM D1816 standard test

5. ASTM D877 standard test

6. 5 minutes standard test

7. Manual test

8. Calibration interface for customers

9. Unloading data to PC and making word report automatically

10. Result print


Specifications:

Power Supply AC220V
Output voltage AC 0V~100KV
Rate of voltage rise 0.5kv/s± 5%, 2kv/s± 5%, 3kv/s± 5%, 5kv/s± 5%
Max test times  9
Stir time 0~999s
Wait time 0~999s
Test error 3% max in the range of 10kv~100kv
Weight 41kg
Size 630 mm*400mm*3000mm



Product Tags: BDV tester , Oil breakdown voltage tester , Oil Breakdown Voltage BDV Tester
