Dezhou Huili product! Enameled sintex water tank/steel plate water storage tank with high intensity
Keywords to understand Huili water tank
SMC/FRP/GRP water tank
Stainless steel water tank
Enameled water tan
Hot dip galvanizing water tank
BDF/CSB underground water tank
All of the water tank can add thermal insulation layer
Product Description
Material:The panel is carbon steel sheet made by ramming craft;
The size of the panel is: 1000*1000mm,1000*500mm, 500*500mm.
The thickness of the panel mainly includes: 5mm, 4.5mm, 3mm, 2.5mm, 2mm, 1.5mm. It is different according to the tank dimension.
Flanges: The sectional panels shall be pressed to double flanges at the angles of 45 degree and 90 degree to the face of the plate on four sides.
Reinforcement Method: All tanks are internally braced with angle stays to endure the rigidity of the tank when filled with the water. The Top panel is supported by top panel support, which shall be made of hot-dipped galvanized material.
Advantages
1. It is not easy to deformation;Strong vibration resistance;Resistance to impact large
2. Enamel water tank is cleaning and hygiene,Ensure no pollution to water quality
3. Composite plate assembly at the scene.Convenient, quick and flexible and adaptable
4. Acid and alkali resistance, corrosion resistance
5. No leaking , sealed performance is good.
6. Storage of hot water is better than other water tank .
7. Enamel water tank level off is smooth, easy to clean.
Selection and using
1.Supply your water tank sizes ,the position of connective pipes and pipe diameter.
2.The water tank can be supplied with the whole sets.
3.Use water storage temperature for 4-65°c.
4.Without other weldments inside and outside the tank,avoiding destroying the enamel surface.
5. The tank should be cleaned regularly ,When testing the water to prevent debris into the box
6.Take over the position of the seams on the board, the company shall be adjusted,pipe
diameter is constant.
Installation and test
1. The water inlet pipe and outlet pipe and overflow pipe diameter, location.
2. The channel around the water tank shall be not less than 600 mm, and the box at the bottom and the top is no less than 500 mm.
3.Water injection test, close the outlet pipe and drain pipe, open the inlet pipe, full, after 24
hours don't ooze water is qualified.
Accessories
Certification
Packaging and delivery
FAQ
1.What's the guarantee, in case the water tank breaks down?
The water tank has one year s guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client s feedback. Parts will be replaced for free if the problems are caused by quality fault.
2.How about the documents after shipment?
After shipment, we will send all original documents to you by DHL, including Packing List,
Commercial Invoice, B/L, and other certificates as required by clients.
3.How long is the delivery time?
For standard water tank less than 100m3, it would be 7-10 days; For non-standard water tank and customized water tank according to client s specific requirements,
it would be 15 to 30 days.
4.How's the payment?
Telegraphic Transfer(T/T).
5.Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
For EXW price, clients need to arrange shipment by themselves or their agents.
6.How is the packing?
Solid Seaworthy plywood Box Package with Steel Belt
Save space as much as possible for container loading
