Hot sell!2015all-around upgrading Huili enameled steel water tank for drinking water
Huili High Quality Enamel Tank Solar Water Tank
Product Description
Material:The panel is carbon steel sheet made by ramming craft;
The size of the panel is: 1000*1000mm,1000*500mm, 500*500mm.
The thickness of the panel mainly includes: 5mm, 4.5mm, 3mm, 2.5mm, 2mm, 1.5mm. It is different according to the tank dimension.
Flanges: The sectional panels shall be pressed to double flanges at the angles of 45 degree and 90 degree to the face of the plate on four sides.
Reinforcement Method: All tanks are internally braced with angle stays to endure the rigidity of the tank when filled with the water. The Top panel is supported by top panel support, which shall be made of hot-dipped galvanized material.
Application
•Storage and regulation of living water supply & construction water supply.
•Temporary water storage tanks for expansion of the heating system, condensate tank and
construction, geological survey, industry, National defense project etc.
•Various industries, civil water supply, HVAC, firefighting, food, beverage, vintage, water
treatment, medicine, petroleum, chemical and so on.
•Taking flexible, reasonable plate design, suitable for all sizes combined water tank.
Suitable for living water with PH value:6.5-8.5, using life:≥20 years
Advantages
1. It is not easy to deformation .
2. Strong vibration resistance
3. Resistance to impact large
4. Enamel water tank is cleaning and hygiene,White and beautiful.Ensure no pollution to water quality
5. Composite plate assembly at the scene.Convenient, quick and flexible and adaptable
6. Acid and alkali resistance, corrosion resistance
7. No leaking , sealed performance is good.
8. Storage of hot water is better than other water tank .
9. Enamel water tank level off is smooth, easy to clean.
Specification parameter
Matters need attention
1. The water inlet pipe and outlet pipe and overflow pipe diameter, location is
determined by the design.
2. The channel around the water tank shall be not less than 600 mm, and the box
at the bottom of the top is no less than 500 mm.
3.Water injection test, close the outlet pipe and drain pipe, open the inlet pipe,
full, after 24 hours don't ooze water is qualified
Our services
1.Professional water tank manufacturer.Customized design is available, OEM and ODM are welcomed.
2.High quality,reasonable&competitive price.High speed forwarder services.
3.Prompt answer on Trademanager and Inquiry,will not delay 24 hours.
Accessories
Certification
Packing&Shipping
1.We usually use plywood or container.Of couse if you have special request,we
would consider seriously.
2.We will delivery products15days once payment arrived.
FAQ
1.What's the guarantee, in case the water tank breaks down?
The water tank has one year s guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client s feedback. Parts will be replaced for free if the problems are caused by quality fault.
2.How about the documents after shipment?
After shipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
3.How long is the delivery time?
For standard water tank less than 100m3, it would be 7-10 days; For non-standard water tank and customized water tank according to client s specific requirements,
it would be 15 to 30 days.
4.How's the payment?
Telegraphic Transfer(T/T).
5.Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
For EXW price, clients need to arrange shipment by themselves or their agents.
6.How is the packing?
Solid Seaworthy plywood Box Package with Steel Belt
Save space as much as possible for container loading
Company introduction
Dezhou Huili tank Co. Ltd., is a professional production enterprise specializing in the
production and design of the water tank.
Company's products include: fiber glass reinforced plastic water tank
stainless steel water tank
enamel steel water tank
hot dip galvanized steel water tank
gush-paint steel water tank
underground water tank
Company tenets: quality first, customer first and best credibility! The same price with best
quality, the same quality with highest reputation!
Our services:The company has a professional aftersale service institution, each service
branch are provided with a fixed installation and after sale service personnel to ensure the user to get a
response from us in the first time.
