Dezhou Huili tank Co. Ltd., is a professional production enterprise specializing in the
production and design of the water tank.
Company's products include: fiber glass reinforced plastic water tank, stainless steel water
tank, enamel steel water tank, hot dip galvanized steel water tank, gush-paint steel water tank
and underground water tank.
Company tenets:
Quality first, customer first and best credibility!
The same price with best quality!
The same quality with highest reputation!
Hot sale!!! Dezhou Huili Enameled water and diesel water tank
Enamel water tank, the use of advanced technology, choose high quality materials, through high heat sintering enamel, make water tank panel forming dense glaze layer, and steel interface between iron penetration.
Panel size
Enamel sheet steel water tank is made of high quality, made into different specifications of the single panel.
Including: 1m × lm,lm×0.5m,0.5m× 0.5m
Advantages
1. It is not easy to deformation .
2. Strong vibration resistance
3. Resistance to impact large
4. Enamel water tank is cleaning and hygiene,White and beautiful.Ensure no pollution to water quality
5. Composite plate assembly at the scene.Convenient, quick and flexible and adaptable
6. Acid and alkali resistance, corrosion resistance
7. No leaking , sealed performance is good.
8. Storage of hot water is better than other water tank .
9. Enamel water tank level off is smooth, easy to clean.
Specification parameter
Nominal volume(m³) |
outline dimension(m) |
Thickness of each panel(mm) |
|||||||
long |
width |
high |
cover panel |
bottom panel |
From the bottom up |
||||
1st layer side panel |
2nd layer side panel |
3rd layer side panel |
4th layer side panel |
||||||
1 |
1 |
1 |
1 |
2 |
2.5 |
2.5 |
/ |
/ |
/ |
6 |
2 |
2 |
1.5 |
3 |
2.5 |
2.5 |
/ |
/ |
|
12 |
3 |
2 |
2 |
3 |
3 |
2.5 |
/ |
/ |
|
15 |
3 |
2 |
2.5 |
3 |
3 |
2.5 |
2.5 |
/ |
|
45 |
6 |
2.5 |
3 |
4 |
4 |
3 |
2.5 |
/ |
|
126 |
9 |
4 |
3.5 |
4 |
4 |
3 |
2.5 |
2.5 |
|
200 |
10 |
5 |
4 |
5 |
4 |
4 |
3 |
2.5 |
|
Matters need attention
1. The water inlet pipe and outlet pipe and overflow pipe diameter, location is determined by the design.
2. The channel around the water tank shall be not less than 600 mm, and the box at the bottom of the top is no less than 500 mm.
3.Water injection test, close the outlet pipe and drain pipe, open the inlet pipe, full, after 24 hours don't ooze water is qualified.
1 Bolt. nut & washers
Option: hot-dipped galvanized material/stainless steel SS304.
2 Sealing material
Sealing material have Rubber strip EPDM, glass cement.
3 Covers
The tank cover shall be constructed from 1.4mm to 3.0mm of thickness hot-dipped galvanized material according to the requirement.
4 Ladders and Level Indicator
Internal & external ladder shall be made of hot-dipped galvanized material/stainless steel SS304.
Successful Case
SMC/GRP/FRP water tank
Stainless steel water tank
Hot dip galvanized water tank
1.What's the guarantee, in case the water tank breaks down?
The water tank has one year s guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client s feedback. Parts will be replaced for free if the problems are caused by quality fault.
2.How about the documents after shipment?
After shipment, we ll send all original documents to you by DHL, including Packing List,
Commercial Invoice, B/L, and other certificates as required by clients.
3.How long is the delivery time?
For standard water tank less than 100m3, it would be 7-10 days; For non-standard water tank and customized water tank according to client s specific requirements,
it would be 15 to 30 days.
4.How's the payment?
Telegraphic Transfer(T/T).
5.Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
For EXW price, clients need to arrange shipment by themselves or their agents.
6.How is the packing?
Solid Seaworthy plywood Box Package with Steel Belt
Save space as much as possible for container loading
