Product Description
Product Name | Triangle Wire |
Diameter | 0.04mm-15mm |
Standard | GB,AISI,ASTM,DIN,EN,JIS, etc |
Surface | Bright, Pickled, Hydrogen annealing |
Application | Tie wire, pins, lashing, forming wire, filters, gaskets, elevators, safety wire, shaped and flat wire, conveyors, jewelry, springs, brush welding, electrical, wire line, craft etc |
Material | 300s:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347 |
Chemical Composition:
Composition, % | ASTM A580/A580M - 13b | |||||||||
UNS-Designation | Type | Carbon | Manganese | Phosphonus | Sulfur | Silicon | Chromium | Nickel | Molybdenum | Nitrogen |
S30200 | 302 | 0.15 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0–19.0 | 8.0–10.0 | . . . | 0.10 |
S30400 | 304 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0–20.0 | 8.0–10.5 | . . . | 0.10 |
S30403 | 304L | 0.030 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0–20.0 | 8.0–12.0 | . . . | 0.10 |
S30900 | 309 | 0.20 | 2.00 | 0.045 | 0.030 | 1.00 | 22.0–24.0 | 12.0–15.0 | . . . | . . . |
S30908 | 309S | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 22.0–24.0 | 12.0–15.0 | . . . | . . . |
S31000 | 310 | 0.25 | 2.00 | 0.045 | 0.030 | 1.50 | 24.0–26.0 | 19.0–22.0 | . . . | . . . |
S31008 | 310S | 0.08 | 2.00 | 0.045 | 0.030 | 1.50 | 24.0–26.0 | 19.0–22.0 | ... | ... |
S31600 | 316 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0–18.0 | 10.0–14.0 | 2.00–3.00 | 0.10 |
S31603 | 316L | 0.030 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0–18.0 | 10.0–14.0 | 2.00–3.00 | 0.10 |
S32100 | 321 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0–19.0 | 9.0–12.0 | ||
S34700 | 347 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0–19.0 | 9.0–13.0 | ||
S40500 | 405 | 0.08 | 1 | 0.04 | 0.030 | 1.00 | 11.5–14.5 | ... | ... | |
S40976 | ... | 0.03 | 1 | 0.04 | 0.030 | 1.00 | 10.5–11.7 | 0.75–1.00 | 0.040 | |
S43000 | 430 | 0.12 | 1 | 0.04 | 0.030 | 1.00 | 16.0–18.0 | ... | ||
S44400 | ... | 0.025 | 1 | 0.04 | 0.030 | 1.00 | 17.5–19.5 | 1.00 | 1.75–2.50 | 0.035 |
S44600 | 446 | 0.2 | 1.5 | 0.04 | 0.030 | 1.00 | 23.0–27.0 | ... | 0.25 | |
S44700 | . . . | 0.01 | 0.3 | 0.025 | 0.020 | 0.20 | 28.0–30.0 | 0.15 | 3.5–4.2 | 0.020 |
S44800 | . . . | 0.01 | 0.3 | 0.025 | 0.020 | 0.20 | 28.0–30.0 | 2.00–2.50 | 3.5–4.2 | 0.020 |
S44535 | . . . | 0.03 | 0.30–0.80 | 0.05 | 0.020 | 0.50 | 20.0–24.0 | . . . | . . . | . . . |
S40300 | 403 | 0.15 | 1 | 0.04 | 0.030 | 0.50 | 11.5–13.0 | . . . | . . . | . . . |
S41000 | 410 | 0.15 | 1 | 0.04 | 0.030 | 1.00 | 11.5–13.5 | . . . | . . . | . . . |
S41400 | 414 | 0.15 | 1 | 0.04 | 0.030 | 1.00 | 11.5–13.5 | 1.25–2.50 | . . . | . . . |
S42000 | 420 | over 0.15 | 1 | 0.04 | 0.030 | 1.00 | 12.0–14.0 | . . . | . . . | . . . |
S43100 | 431 | 0.2 | 1 | 0.04 | 0.030 | 1.00 | 15.0–17.0 | 1.25–2.50 | ` | . . . |
S44002 | 440A | 0.60–0.75 | 1 | 0.04 | 0.030 | 1.00 | 16.0–18.0 | . . . | 0.75 | . . . |
S44003 | 440B | 0.75–0.95 | 1 | 0.04 | 0.030 | 1.00 | 16.0–18.0 | . . . | 0.75 | . . . |
S44004 | 440C | 0.95–1.20 | 1 | 0.04 | 0.030 | 1.00 | 16.0–18.0 | . . . | 0.75 | . . . |
Product Flow
Related Wires
Company Information
Wenzhou Taixin Stainless Steel Co., Ltd is founded in 1998, Taixin now covers a total landing area 320,000 square meters and more than 300 employees.
We have developed a full set of equipment to offer customer high quality materials with very competitive price.
The stainless steel and alloy triangle wire supplied by wenzhou taixin stainless steel co.,ltd will help you enjoy good quality and expand market.
Quality Control
Application
wire drawing, weaving nets, hoses, steel wire rope, electro polishing quality wire, Special shaped rods, filter equipment, stranded wire, spring wire, profiling wire, welding wire stainless steel sieve tube ,oil and other products.
Package
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 30% T/T in advance, balance before shipment.
If you have another question, pls feel free to contact us freely.
