Home > Packaging & Printing > Packing Machinery > Wrapping Machine > Granule Packaging Machinery

Granule Packaging Machinery

Granule Packaging Machinery photo-1
Granule Packaging Machinery photo-2
Negotiable MOQ: 30 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Commodity, Food, Other, Medical, Commodity, Food, Machinery & Hardware, Medical
Packaging Type:
Film, Pouch, Stand-up Pouch
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Commodity, Food, Other, Medical, Commodity, Food, Machinery & Hardware, Medical
Packaging Type Film, Pouch, Stand-up Pouch
Packaging Material Other, film
Automatic Grade Automatic
Driven Type Electric
Voltage 380v
Power 5kw
Place of Origin Jiangsu, China
Brand Name Haitel
Model Number HTL-D420
Weight 900KG
Certification CE, ISO9001
After-sales Service Provided Engineers available to service machinery overseas

 HTL-D420  Full Automatic Granule

Auger Vertical Packaging Machinery



1. Machine Picture





2. Characteristics:

1. Film drawing down system controlled by servo motor.

2. Automatic film rectifying deviation function.

3. Various alarm system to reduce waste.

4. It can complete feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, finished product delivery when it equips with feeding and measuring equipment.

5. The way of bag making: The machine can make pillow-type bag and standing-bevel bag, punch bag or according to customer’s requirements.



3. Application:

       It is suitable for packing of several of granule, powder, such as sugar, salt, coffee, etc.



4. Main technical parameters:

Model

HTL-D420

Packing speed

About 30-60 bags/min. It is according to quality of wrapping film and materials.

Accuracy

1.5%

Bag size

(L) 80-300 mm; (W)80-180 mm

Maximum film width

420 mm

Filling range

50-1000 g

Film thickness

0.04-0.09 mm

Packing material

Thermal composite materials, such as BOPP/CPP, PET/AL/PE

Air consumption

0.8 MPa, 0.4 m³/min

Total power

5 KW

Voltage (V)

Four wires, three phases, 380V, 50Hz.

Air compressor

Not less than 1 CBM

Total height

2528 mm

Gross weight

900 kg





5. Electric configuration:

1

Touch-sensitive screen

WEINVIEW                 Taiwan

color screen

2

Programmer controlled system

SIEMENS                    Germany



3

Servo motor

PANASONIC              Japan



4

Servo driver



5

Cylinder

SMC                             Japan



6

Cylinder

SMC                             Japan



7

Electromagnetic valve

JINGQI                         Taiwan



8

Intermediate relay

Weidmuller                    Germany



9

Photoelectric eye

BEDELI                        Taiwan



10

Powder

ZHANGXIN                 China



11

Solid state relay

XIANLI / OMRON



12

Thermometer control

OMRON







6. Packing Product samples:
