GDBC-901 Three Phase Transformer Turns Ratio TTR Tester

Chongqing Gold Mech
GDBC-901 Three Phase Transformer Turns Ratio TTR Tester thumbnail-1
GDBC-901 Three Phase Transformer Turns Ratio TTR Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GDBC-901
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GDBC-901

Introduction:
1. The voltage ratio measurement for three or singe phase transformer

2. The group vector measurement for three phase transformer.

3. The polarity measurement for single phase transformer or CT/PT

4. Voltage ratio error calculation

5. Current transformer ratio measurement

6. Excitation current measurement in ratio testing

7. Reproduction the AC test voltage from power source to reduce the effects of bad power source

8. Save the test results in the memory internal the tester

9. Print the test results by micro printer

10. Reverse connection detect unit to prevent the high voltage injected to operator

11. Over current protection unit integrated in software and hardware

12. Upload the test results to PC by RS232 and make word report by software



Specifications:

Ratio measurement range 1~10000
Group measurement 1~12
Phase measurement error 1 degree
Ratio measurement error 1~2000 ± 0.2%RDG
 2000~10000 ± 0.5%RDG
Test voltage 0~80V
Power supply AC220V ± 10%, 50Hz/60Hz
Size 400´350´200 mm3
Weight 7kg Humidity ≤85%RH
Product Tags: TTR event tester , Z-type winding transformer , Transformer rotation ratio tester
