GDRZ-902 Transformer SFRA Sweep Frequency Response Analyzer

GDRZ-902 Transformer SFRA Sweep Frequency Response Analyzer thumbnail-1
GDRZ-902 Transformer SFRA Sweep Frequency Response Analyzer photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GDRZ-902
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GDRZ-902

Introduction:
1. Using the advanced technical of DDS.

2. Using the high speed and advanced micropr℃essor to design.

3. Using double channels of AD chip of 16 bits.

4. With seven inch LCD touch screen of which the brightness can be adjusted.

5. With thermal printer of which the print thick can be adjusted.

6. It could store one hundred and twenty groups of data, which could be read to current screen or upload to the PC.

7. With PC software using which we could upload data ,test, analyze data, print data, or create word d℃ument.

8. Using USB2.0 to connect to the device.

9. Tester dimension:31cm * 15cm * 15cm

10. Weight:4.0KG.


Specifications:

Two different sweep modes Linear sweep,Section sweep
Linear sweep 0.5KHZ-1MHZ interval 0.5KHZ 2000 dots
Section sweep 50HZ-100HZ interval 2HZ 25 dots
100HZ-1KHZ interval 20HZ 45 dots
1KHZ -10KHZ interval 50HZ 180 dots
10KHZ-100KHZ interval 0.2KHZ 450 dots
100KHZ – 500KHZ interval 0.5KHZ 800 dots
500KHZ – 1000KHZ interval 1KHZ 500 dots
Test range (-100dB) - (+20dB)
Test accuracy 0.1dB
Frequency accuracy
Signal input impedance >1M Ω
Signal output impedance 50 Ω
Product Tags: Response analyzer , Transformer analyzer , Sweep Frequency Response Analyzer
