GDGK-303 Low Price Circuit Breaker Analyzer

Chongqing Gold Mech
GDGK-303 Low Price Circuit Breaker Analyzer thumbnail-1
GDGK-303 Low Price Circuit Breaker Analyzer photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GDGK303
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GDGK303

Introduction:
1.GDGK-303 circuit breaker analyzer is designed to meet the need of testing high_voltage switches .

2.It takes the micro controller unit(MCU) for core to sample, process and then output; the main characteristic is that it’s operated in Chinese, for example ,the results are displayed and printed in Chinese.

3.It has many advantages such as intelligence, multi-function, accurate data, strong anti-jamming, easy operation, small size, beautiful appearance, etc;

4.It can test the switches as follows:indoors or outdoors switches with less oil or more oil,vacuum switches, SF6 switches and so on.


Features:

1.Closing and opening time measurement of 12 channels

2.Max difference of closing or opening time measurement of three phases

3.Bounce time and frequency measurement of breaker closing

4.Circuit breaker closing and opening speed measurement

5.Travel-time, Coil current-time curve of circuit breaker operation measurement
Clearance of circuit breaker measurement

6.Variable DC circuit breaker operation power supply

7.Print test results by internal micro printers


Specification

Time measurement range6000ms, resolution 0.1ms
Time measurement error<1%RDG+0.2ms
Speed measurementRange 2m/s resolution 0.01m/s max error<0.1m/s
Range 20m/s resolution 0.01m/s max error<0.2m/s
Travel measurementRange 250.0mmresolution 1mmmax error 1mm

DC Power outDC30V~250V/10A (instantaneous)

Travel sensors configurationgrating and angle

Test standardIEC62271
LCD128*64
Power supplyAC220V±10% 50Hz/60Hz
Working ConditionTemperature: 0~50°C humidity: <85%

Product Tags: Circuit breaker analyzer , High voltage switch , Low Price Circuit Breaker Analyzer
