Specifications
Stone Crasher LineHigh Productivity;
Energy saving;
Econmical and practical;
Fine crushing result
200-250TPH Stone Crasher Line
Introduction of Stone Crasher Line
1. Primary Crushing: 200-250 ton per hour Quartz Stone Production Line exploits PE750X1060 jaw crusher for primary crushing. In practical production, through enlarging the outlet size, the overall output and production efficiency are improved greatly, meanwhile, the service time of machine is extended and production cost is reduced.
2.Secondary Crushing of Stone Crasher Line
PF-1214 two impact crushers operates at the same time, which ensures its output. The reduction ratio can be controlled by regulating the impact-bracket. The finished products are expected to be regular cube-shaped, needle shape take up small proportion, no inner-cracks, with high compressive strength. They are quite suitable for speedway, bridge, tunnel and other construction projects.
3. Stone Crasher Line
By utilizing a more efficient Round Vibrating Screen during the filtration processing, the raw material is more precisely and sufficiently classified.
This production line can also be perfected by other supplementary equipments so as to get further processing products.
Main Components of Stone Crasher Line
Vibrating Feeder ZSW 490 x110
Max Feeding Size: ≤630mm
Power: 15 kw
Jaw Crusher PE-750 X 1060
Max Feeding Size: ≤630mm
Power: 110kw
Impact Crusher PF-1214 / 2 units
Max Feeding Size: ≤350mm
Power: 132kw x 2
Vibrating Screen 3YK 2160
Sep1=40mm Sep2=20mm Sep3=5mm
Power: 30kw
Auxiliary Components of Stone Crasher Line
Belt Conveyor
B1000 X 18M
B1000 X 21M
B650 X 23M
B650 X 18M
B650 X 18M
B650 X 18M
Control system
Electronic Control Cabinet
