2013 Hammer Mill for Stone Crushing

2013 Hammer Mill for Stone Crushing thumbnail-1
2013 Hammer Mill for Stone Crushing photo-1
US$ 2,666 - 56,666 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Hammer Crusher
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Zhengzhou Unique Industrial Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao; Shanghai; Tianjin etc.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Hammer Crusher
Place of Origin Henan, China
Brand Name UNIQUE
After-sales Service Provided Engineers available to service machinery overseas
Application coal, salt, plaster, alum, brick, tile and limestone

Specifications

Hammer Mill for Stone Crushing:
1. High reduction ratio;
2. High effiency;
3. Energy saving;
4. Easy mainenance...

2013 Hammer Mill for Stone Crushing



2013 Hammer Mill for Stone Crushing



Usage of Hammer Mill for Stone Crushing

Hammer crusher is applicable for brittle minerals crushing, such as coal, salt, plaster, alum, brick, tile and limestone with compression strength no more than 100mpa and humidity no more than 15%.



Operating Principle of Hammer Mill for Stone Crushing

The main working part of hammer crusher is rotors with hammer. The rotors consist of main shaft, disk, pin shaft and hammers. The motor drives the rotors to rotate quickly in the crushing cavity. Raw materials enter the crusher through the feed opening and are stricken, impacted, cut and ground by the high-speed hammer to small size. There is a screening plate under the rotor, so that materials with size smaller than the screen mesh will be screened out and others are left to be further hammered and ground until reach the standard size.



Specification of Hammer Mill for Stone Crushing

Type

Specifications

Feeding
size(mm)

Discharging
size(mm)

Capacity
(m3/h)

Motor

Power
(kw)

Total
weight
(t)

Dimensions
(L*W*H)(mm)

Hammer
Crusher

HC400*300

<=200

<=25

5-10

11

0.8

900*670*860

HC600*400

<=250

<=30

10-22

22

2.26

1200*1050*1200

HC800*600

<=250

<=35

18-40

55

4.8

1310*1180*1310

HC1000*800

<=350

<=35

25-50

75

5.9

1600*1390*1575

 HC1000*1000

<=350

<=35

30-55

90

8

1800*1590*1775

 HC1250*1250

<=350

<=35

35-65

132

14

2060*1600*1890

 HC1400*1400

<=350

<=35

50-100

280

32

2365*1870*2220

 HC1600*1600

<=350

<=35

100-150

480

37.5

3050*2850*2800
