China heavy limestone hammer mill DPX-125 for Cement Plant

Specifications

rock on rock crushing|
max. input size can reach 1100mm|
Output: 3-50mm adjustable|
Large production capacity|
Longer life





Introduction

DPX hammer crusher is one of the dominant products of our company, and it is suitable for material compressive strength less than 150MPa, such as limestone, clay limestone, sandstone, shale, gypsum, coal, etc







Feature



1.Tri-cavity curved designed , which increased the breaking times of materials . the “rock-on-rock” principle indeed reduce the friction , wear of hammers and also consumption of energy.
2.High crushing ratio , small granularity (D80≤8mm)
3.Easy adjusting for the gap between liner plate and hammers. The discharing size of final products can also been adjusted from 3-30mm .
4.Energy saving over 40% than multi-stage crushers.
5.Long service life, lower cost of operating, maintenance.









Working principle

DPX series single stage hammer crusher has big crushing cavity and feeding opening , which can ensure lump ore be feeded smoothly . the special designed rotor can break the materail easily for increasing the crushing efficiency . the forward way grid plate improves the conditions of passing materials, so the grid plate will not jam even if the materials contain clay. Structure of the frame is very strong , although iron been feeded  it will not damage the working parts . and the iron will be discharged from the discharging opening at the bottom of rotor





Technology parameter

Specifications	Feed size D(mm)	Discharge size D(mm)	Capacity (t/h)	Hammer life (million tons/set)	Power(kw)
DPX-15	≤500	apply to stone production line: d=5-40  adjustable	15~35	1~2	30~45
DPX-35	≤700		35~60	3~5	55~75
DPX-65	≤800		60~90	5~8	90~132
DPX-90	≤900		90~125	8~12	160~200
DPX-125	≤1100	apply to stone production line: d=5-40  adjustable	120~150	13~15	200~240
DPX-150			150~180	15~18	280~315
DPX-180			180~250	18~22	355~380
DPX-250	≤1300		250~400	22~28	560~630
DPX-300			450~650	30~40	710~800
