Best JS2000 Italy Technology Twin Shaft Concrete Mixers

Specifications

JS2000 Twin Shaft Concrete Mixers

Description of JS2000-4000 Twin Shaft Concrete Mixers :
JS2000-4000 electric concrete mixer is an important concrete mixing machine in our company. Multi-stirring piece design and unique mixing angle make the mixing faster and more uniform, which can improve the production efficiency. Water is injected into the concrete mixer, which accelerates the mixing of water and mix materials as well as thoroughly cleans it.

Features of JS2000  Twin Shaft Concrete Mixers :
1.This concrete mixer uses high-chromium and high-molybdenum scale boards and stirring pieces, with a long service time.
2. Shaft seal is applied with patented air pressure seal, which can effectively prevent the leakage of mortars.
3. Auto-lubrication system ensures the mixing system can operate continually for a long time.
4. Opening gates mechanism directed by hydraulic can adjust the opening angle of discharging door in accordance with the need, which effectively prevents overspill while discharging the finished materials into truck-mounted concrete mixers.

Application of JS2000 Twin Shaft Concrete Mixers :
This concrete mixer is ideal for mixing stiff-consistency concrete, semi-stiff-consistency concrete, plastic concrete and other kinds of concrete in different proportional ratios.

Technical Specification of JS2000  Twin Shaft Concrete Mixers :

Model: JS2000

Discharge volume: 2000L

Charging volume: 3200L

Theoretical capacity: ≥100m³

Aggregate sizes: ≤60/80mm

Working circle: 60s

Mixing blade

Speed: 23.1r/min

Quantity: 2×9

Mixing motor

Model: Y25M-4

Power: 2×37 kw

Weight: 9200kg

Dimensions (L x W x H): 3810x2480x1710 mm
