Help Center2013 High Pressure Gemstone Drilling Machine KY140A
Related Products
-
Always Hot Sale Rock Drill Wagon for Borehole, Crawler Rig for BlastholeNegotiableMOQ: 1 Set -
Unique Crawler Rock Driller KY120 In Stock!!!NegotiableMOQ: 1 Set
-
China High Quality Crawler Rock Drilling Machine for Mining ExplosionNegotiableMOQ: 1 Set
-
High Efficiency Powerful Diesel Granite Drilling Rig KY140A for BoreholeNegotiableMOQ: 1 Set
-
China Hot Selling Powerful DTH Track Drill for MiningNegotiableMOQ: 1 Set
Specifications
stone drilling machinepowerful & reliable engine
adjustable boom
reliable hydraulic system & pump sets
long service life
Crawler Drill is widely used in quarry, railway, road, water and electricity, open-pit mines and construction work site to do deep or medium-deep rock hole drilling operations. Woring with the screw air compressor and the impactor(DTH hammer), it can drill horizontal, vertical, inclined blast hole, pre-hole and anchor bolt holes.
Specifications of Crawler Drill KY140A
Rock rigidity: f=6-20
Dia. of hole: 105-140 mm
Optimum drilling depth: 25 m
Working pressure: 10-24 bar
Air consumption: ≥16m3/min.
Rotation speed: 0-63 rpm
Torque: 3200 N•m
Lift power: 20 KN
Dimension: 5400x2330x2020 mm
Weight: 5500 kg
Drive system: YC 4D80-T10
Specification of Matched Mobile Screw Air Compressor LGCY-18/17
Air capacity: 18m3/min.
Work pressure: 17bar
Fluid capacity: 48L
Compression stage: double
Diesel engine: Cummins 6CTA8.3-C260 (194kw/260HP)
Dimensions: 3650x1800x2500 mm
Total weight: 3700 kg
