2015 China High Quality Small Scale Cement Mill for Sale
- 2000 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T Credit Card
Product Details
Condition: | New | Type: | Ball Mill | Motor Type: | AC Motor |
Power(W): | 7.5-1250kw | Capacity(t/h): | 0.1-70 | Place of Origin: | Henan, China |
Brand Name: | UNIQUE | Model Number: | as per model | Dimension(L*W*H): | as per model |
Weight: | as per spec | Certification: | ISO | Warranty: | 15 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
The ball mill is mineral processing equipment, mainly applied in ore crushing/grinding in the mining, used for grinding various ores and other materials. It’s widely employed in mineral processing, building materials and chemical industries, can be divided into dry and wet grinding.
According to the different ways of discharging, it can be divided into lattice type and overflow type. Facing the development of the market situation, the ball mill has been gradually developed many types, to meet different materials and scales, type will be used is not the same as well.
Generally speaking, a direct way to improve ball mill output has three kinds:
1. Placing a fine crusher before the Ball mill
2. Improve grinding system to improve grinding efficiency
3. Add high efficiency classifiers
For the above three methods, any one kind can significantly improve the yield of the ball mill. Of course, if the factory conditions permits, the effect of matting use of the above-mentioned three methods is the most ideal, which is big trend at home and abroad in grinding system design recent years.
Technical Parameters of models (we also can customize non-standard model as per request)
Type | Model | drum (mm) | volume (m3) | revolution (r/min) | motor (KW) | discharging size (mm) | Output (t/h) |
Wet-Grate Ball Mills | MQ1530 | 1500×3000 | 4.5 | 26.5-29.8 | 95 | 0.3-0.074 | 6.1-3.1 |
MQ2130 | 2100×3000 | 9.2 | 22.2-25.2 | 210 | 0.3-0.074 | 14-6.4 | |
MQ2430 | 2400×3000 | 12.2 | 20.8-23.5 | 240 | 0.3-0.074 | 18.5-8.7 | |
MQ2736 | 2700×3600 | 18.4 | 19.6-22.2 | 400 | 0.3-0.074 | 28-13 | |
MQ3245 | 3200×4500 | 32.8 | 18-20.4 | 800 | 0.3-0.074 | 49-24 | |
MQ3660 | 3600×6000 | 54.4 | 17-19.2 | 1600 | 0.3-0.074 | 82-38 | |
Dry-Grate Ball Mills
| MQG1515 | 1500×1500 | 2.2 | 26.5-29.8 | 60 | 0.4-0.074 | 5.2-1.9 |
MQG1522 | 1500×2250 | 3.4 | 26.5-29.8 | 75 | 0.4-0.074 | 10.2-2.7 | |
MQG1530 | 1500×3000 | 4.5 | 26.5-29.8 | 95 | 0.4-0.074 | 14-3.6 | |
MQG2122 | 2100×2200 | 6.7 | 22.2-25.2 | 155 | 0.4-0.074 | 25-5 | |
MQG2424 | 2400×2400 | 9.8 | 20.8-23.5 | 210 | 0.4-0.074 | 29-7.5 | |
MQG2430 | 2400×3000 | 12.2 | 20.8-23.5 | 240 | 0.4-0.074 | 38-9.5 | |
Over-flow Ball Mills
| MQY1530 | 1500×3000 | 4.5 | 26.5-29.8 | 95 | 0.3-0.074 | 6-2.8 |
MQY2136 | 2100×3600 | 11 | 19-25.2 | 210 | 0.3-0.074 | 12.8-6 | |
MQY2430 | 2400×3000 | 12.2 | 17.8-23.5 | 240 | 0.3-0.074 | 16.6-7.8 | |
MQY2740 | 2700×4000 | 20.4 | 16.8-22.2 | 400 | 0.3-0.074 | 27.7-13 | |
MQY3254 | 3200×5400 | 39.4 | 15.5-20.4 | 1000 | 0.3-0.074 | 52.8-25.9 | |
MQY3660 | 3600×6000 | 54.4 | 14.5-19.2 | 1250 | 0.3-0.074 | 74.1-32.4 |
Welcome to send inquiry any time for stone/minearl crushing, screening & grinding equipment. Best solution will be provided for you shortly. Thank you!
