Gap Bed Lathe With Swing Over Bed 360 410 460mm

Shaanxi Olong Import And Export Co., Ltd.

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Model Number:

1880ZX 1860ZX 1840ZX 1660ZX 1640ZX 1460XZ 1440ZX

Certification:

CE ISO

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Model Number 1880ZX 1860ZX 1840ZX 1660ZX 1640ZX 1460XZ 1440ZX

Certification CE ISO

		C6246ZX			C6240ZX			C6236ZX
		1880ZX	1860ZX	1840ZX	1660ZX		1640ZX	1460XZ	1440ZX
Max. swing over bed	mm	Φ460(18")			Φ410(16")			Φ360(14")
Max. swing over carriage	mm	Φ290(10-4/5")			Φ25010")			Φ200(7-2/3")
* Max. swing over gap	mm	Φ700(27-1/2")			Φ660(26")			Φ600(23-5/8")
*Max. length of work piece(two centers)	mm	2000(80”) 1500(60”) 1000(40”) 1500(60”)			1500(60”)		1000(40”)	1500(60”)		1000(40”)
*Effective length of gap	mm	200(8")
Spindle nose	mm	Φ80(3-1/8")
Spindle taper of bore		M.T.No.7
Number of speeds		12
Range of speeds	rpm	42~1800 or 25~1800			42~1800 or 25~1800			42~1800
Thread cutting for Metric pitch threads	Range/No.	0.5~20mm/24
Thread cutting for Whit-worth pitch threads	Range/No.	72~1.5/8 t.p.i/61
Thread cutting for Module threads	Range/No.	96~3.-1/4 D.P/45
Thread cutting for D.P. threads	Range/No.	0.25~10 M.P/20
Range of feeds for longitudinal	mm	0.04~2.46(0.0015"-0.0913")
Range of feeds for cross	mm	0.02~1.23(0.005"-0.0365")
Tailstock sleeve dia.	mm	Φ75(3")
Tailstock taper of bore	mm	M.T.No.5				M.T.No.4
Tailstock sleeve max. travel	mm	130(5")
Max. travel of compound rest	mm	100(4")
Max. cross slide travel	mm	280 (11")
Max. size of tool shank(WxH)	mm	25×25(1”×1")
Power of main motor	kw	5.5

ITEM		C6246ZX				C6240ZX			C6236ZX
		1880ZX	1860ZX	1840ZX		1660ZX	1640ZX		1460ZX	1440ZX
Max. swing over bed	mm	Φ460(18")				Φ410(16")			Φ360(14")
Max. swing over carriage	mm	Φ290(10-4/5")				Φ250(10")			Φ200(7-2/3")
* Max. swing over gap	mm	Φ700(27-1/2")				Φ660(26")			Φ600(23-5/8")
*Max. length of work piece(two centers)	mm	2000(80”) 1500(60”) 1000(40”) 1500(60”)				1500(60”)	1000(40”)		1500(60”)	1000(40”)
*Effective length of gap	mm	200(8")
Spindle nose	mm	Φ80(3-1/8")
Spindle taper of bore		M.T.No.7
Number of speeds		12
Range of speeds	rpm	42~1800 or 25~1800				42~1800 or 25~1800		42~1800
Thread cutting for Metric pitch threads	Range/No.	0.5~20mm/24
Thread cutting for Whit-worth pitch threads	Range/No.	72~1-5/8 t.p.i/61
Thread cutting for Module threads	Range/No.	96~3-1/4 D.P/45
Thread cutting for D.P. threads	Range/No.	0.25~10 M.P/20
Range of feeds for longitudinal	mm	0.04~2.46(0.0015"-0.0913")
Range of feeds for cross	mm	0.02~1.23(0.005"-0.0365")
Tailstock sleeve dia.	mm	Φ75(3")
Tailstock taper of bore	mm	M.T.No.5			M.T.No.4
Tailstock sleeve max. travel	mm	130(5")
Max. travel of compound rest	mm	100(4")
Max. cross slide travel	mm	280 (11")
Max. size of tool shank(WxH)	mm	25×25(1”×1")
Power of main motor	kw	5.5
