FX-8 Full-automatic Grab Lid Capper Machine For Plastic Thread Cap

Introduction

The machine used straight bottle feeding and control by PLC program . Bottles will be fixed by two cylinders and it can automatically arrange lid , taking lid and sending lid,it will first grasp lid then capping under control of double-acting cylinder lifting stroke. The machine grasp lids through pneumatic type, lid-revolving head has a clutch to ensure the tightened lid not to damage. It suits for capping of 5-25kg drum plastic large diameter caps.

Advantages

with PLC control system,

♦ Electrical components - using internationally renowned brands, ensuring that equipment is reliable and of high accuracy.

♦ Mechanical components - Capping motor is from China famous brand, the rest parts of the machine are made of high-quality stainless steel 304.

Function extensions - can be customized for special requirements allocation, for example: cap unscrambler can be attached or removed.

Maintenance situations - the machine meet the GMP requirements, easy to disassemble, clean and maintain..

Function with - this machine comes with lid device management, anti-covered self-excluded

Exchange specifications – when changing filling specifications, you only need some simple adjusting to make it.

♦ Environmental configuration - the framework of environmental protection can be configured so that the operating environment is cleaner. (This function is customized on request)

Parameters

♦ Production capacity: ≤1500 BPH

♦ Suitable bottle diameter:  ≤320(L)×220(W)mm

♦ Applicable bottle height: 250-450mm
♦ Cap specification: ≤Φ75 mm

♦ Compressed air pressure: 0.6~0.8 Mpa

♦ Voltage: AC380V, 50/60Hz

♦ Total power: 2Kw
♦ Overall dimension: 2000(L)×1030(W)×2100(H)mm
♦ Weight: 400 Kg

♦ Remark: We supply customized service
