Specifications
1.Suitable for aluminium cap
2.Rotary type with high efficiency and excellent performance
3.4, 6, 8 heads can be choosen
Introduction
The machine suits for the revolving, rolling and sealing of the aluminum lid and glass bottle, polyester bottle and plastic bottle, it can feed bottle, arrange lid, cover lid and remove the reversed lid automatically, under the rolling and pressing of the revolving rolling blade, complete the screws pressing working procedure to realize the end of the mouth sealing. The lid to be rolled and pressed, has good seal performance, convenient lid-opening, plays the role of anti-stealing and anti-counterfeit.
Advantages
♦ Control panel - Using knob controls on traditional control panel, simple operation, stable and reliable.
♦ Real-time alarm - Automatic alarming when the fault happens, automatic stopping and alarming when the system appears serious breakdown.
♦ Electrical elements - Adopting international famous brand to ensure the remarkable quality, stability and high precision.
♦ Machine elements - The main parts of this machine all use the 304 high-class stainless steel.
♦ Turntable positioning - It is an capping machine having positioning design according to the sample bottles offered by the customers
♦ Maintenance condition - Fully accords to the GMP requirements, easy to disassemble and clean
♦ Additional function - This machine is equipped with cap unscrambled , reverse cap can be removed automatically
♦ Changing specification - No need to change any components, easy to realize changing the cap types by simple adjusting
♦ Environmental protection configuration - Equipped with eco-friendly frame, realizing more clean and sanitary operation environment.(this function needs to be made to order )
Parameters
♦ Capping head no.: 4, 6, 8 opitional
♦ Voltage: 220V, 380V or customized
♦ Suitable bottle diameter: design according to the sample bottle
♦ Cap unscrambler: design according to the cap
♦ Suitable cap diameter: 28 - 72 mm
♦ Trimming correction: ≥99.99%
♦ Production speed: 3000~8000bottles/hour
♦Suiting for lid: Aluminum lid
♦Suiting for the bottle lid-sealing of 250-1000ml
♦ Air source requirements: Stable 0.55Mpa-0.65Mpa air
♦Net weight: 700kg
♦ Contour Size: 2000×1100×2000mm
