ISO 5660, ASTM E 1354, BS 476-15 Cone Calorimeter

ISO 5660, ASTM E 1354, BS 476-15 Cone Calorimeter thumbnail-1
ISO 5660, ASTM E 1354, BS 476-15 Cone Calorimeter photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GD-07007
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GD-07007

Introduction：
When the specimen is exposed to a heat source by conical heater, the instrument can measure: rate of heat release, smoke release rate, time to ignition, Oxygen consumption, mass loss rate, rate of toxic gas release like CO, CO2.
User friendly DAQ system for easy operation. Operator set the same temperature as that of real fire, change the specimen temperature, temperature elevated time and collect data. The acquired data is referential for real fire atmosphere.


Feature:
1.Compact design of 19 inch PC display
2.User friendly DAQ system for easy operation
3.Spark ignition for testing burn time
4.Glass window to keep safety , and easy for observing
5.Gas analyzer measures the concentration of O2, CO, CO2, +/-0.01%
6.MFC control gas flux accurately
7.Heat Flux meter, portable water cooling system without running water supply
8.Weighing sensor enables mass loss rate accurately
9.Smoke density analyzer with laser system
10.Test Data :HRR, THR,EHC,TTI,MLR,SPR,Total Smoke Amount ,CO2/CO production etc.

Specifications:

Model GD-07007 ISO 5660, ASTM E 1354, BS 476-15 Cone Calorimeter
Dimension 1800(W)×830(D)×2700(H)mm
Power supply AC 220V, 50/60Hz, 30A
Weight About 350kg
Accessories CH4>99.5% purity , Standard Gas(CO2 8.5% , CO 0.85% , N2)


Product Tags: DAQ system , Cone Calorimeter , Toxic gas release rate tester
