Conical Twin-Screw Plastic Extruder Gearbox Series/gear Box High and Low
US$ 2,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Putuoshan
Model Number:
Many types
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai seaport
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality Single Screw Extruder Gear Box for Extruder MachinesUS$ 300 - 10,000MOQ: 1 Set -
Single Plastic Screw Extruder Gear BoxNegotiableMOQ: 1 Set
-
Vertical Single Screw Warm Gear BoxUS$ 400 - 10,000MOQ: 1 Set
-
Gearbox Gear Box Gearboxes for PVC Pipe Extruder Plastic Processing MachineNegotiableMOQ: 1 Set
-
Double Screw Extruder Warm Gear BoxUS$ 4,500 - 20,000MOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Putuoshan
Model Number
Many types
Gearing Arrangement
Other, Helical, Hard Gear Surface
Output Torque
6786N.M
Rated Power
55KW
Input Speed
1500r/min
Output Speed
38.7r/min
Specifications
Conical Gear box for the double screw and barrel extruderGear box for the double screw and barrel extruder .
The main technical performance table in the gearbox process are:
| SZ45 | SZ50 | SZ55 | SZ65 | SZ80 | SZ92 |
Input speed max r/min | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
Output speed max r/min | 44.8 | 37.8 | 37.5 | 39.1 | 37.7 | 40 |
Input power kw | 18.5 | 22 | 30 | 37 | 55 | 110 |
Uniaxial torque output N.m | 1972 | 2779 | 3820 | 4518 | 6786 | 13130 |
Axis angle distribution | 2°40' | 2°58'12" | 2°36'14" | 2°11'16" | 2°0'18" | 1°52'3.64" |
Connect spline size | 8-48×42×8 | 8-48×46×9 | 6-60×53×14 | 8-65×56×10 | 8-72×62×12 | 10-98×92×14 |
