Home > Products > tire recycling machine > tire bead extracting machine
tire bead extracting machine
- 15 Set / Sets per Month
- Shanghai Port
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Tire Machine | Tire Machine Type: | Tire Bead Machine |
Place of Origin: | Jiangsu, China | Brand Name: | SUMAC | Model Number: | SL-1200 |
Voltage: | 380V | Power(W): | 15kw | Dimension(L*W*H): | 2250*1650*1500 mm |
Weight: | 6500 kg | Certification: | CE ISO SGS | Warranty: | 13 Month |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
tire bead extracting machine
The machine is used to pull out the both beads wires from the waste tires completely at the same time.The machine is composed of main shaft supporting board, cross hole blocking board, blocking plate supporting board, bracket, upper crutch, speed reducer, motor, transmission gears, main shaft and control cabinet, etc.
* The machine use integral base pedestal, easy installation and operation, it is the most efficient debeader in the current market;
* Adopts the motor and twin hooks, design to pull out bead wires at 3 times the speed of the single hook debeader.
* Mechanical transmission and round hook design, high efficient and small occupation area.
* Circuit protection system, safety protection frame to make the operation easy and safe.
* Round hook, cross hole plate and gears are made of materials after special treatment, wearable, heavy-duty, easy maintenance and long life.
Model | SL-1200 |
Capacity | 60~120pcs/hour |
Type of tires | ≤1200mm |
Powder | 15KW |
Pulling force | 30T |
Weight | 6500kg |
Dimension | 2250x1660x1500mm |
The waste tire after remove the tire bead steel wire:
Why we need to remove the steel wire of the tire bead ?
--To increase the life of the tire shredder's knives,(the price of tire shredder's knife is about USD 1000/pc,the tire shredder has 20pcs knives.
TO MAKE SURE BETTER QUALITY
1) We use motor from Siemens,ABB/WEG is ok for your requirement
2) We adopts electrical control parts from CHNT/Schneider/Delixi
3) We use bearings from SKF
Our Service
Pre-Sales Service
* Inquiry and consulting support with 24 hours
* Sample testing support.
* View our Factory.
After-Sales Service
* Instructing how to install the machine, insutructing how to use the machine.
* Engineers available to service machinery overseas.
*Training your worker how to operate the machinery
PACKING AND SHIPPING
The normal package is wooden box(Size: L*W*H).
If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
If machine is big, we will fix the machine inside container with steel wires and nails.Machine won't move inside the container.
