Product Features
1. Adopting near-infrared light source to fill light, good concealment, not easy to be detected
2. Specialized high definition night vision laser homogenization technology, laser spot high brightness and good homogenization of laser spot, exquisite image with no noise
3. 20* day and night low light 2 megapixels color to black camera, realizing day and night continuous monitoring
4. Super large angle continuous servo synchronous zooming laser illuminator, MMA inside optical axis fine adjustment aligned technology
5. High performance embedded processor, adopting high efficiency H264 compression algorithm, clear, real time and smooth video
6. Supporting dual stream, small time delay, fully satisfying different network bandwidth
7. Fully supporting ONVIF、GB/T28181, providing SDK, can docking with main monitoring platform home and abroad
8. Supporting WEB browsing video, providing access to NVR platform to conduct uniform parameter configuration and operation state management
9. Humanized design, high intelligence, supporting 3D locating, power off memory, zooming and speed changing
10. Adopting high performance power supply program, wide voltage input, low power consumption, suitable for special power supply mode such as solar energy
11. IP66 protection grade,2000V anti-lightning, adapting to all kinds of complex environment
12. Professionally designed shell, artistic, light, firm, anti-high temp, anti-corrosion, water proof, anti-acid rain
Specification
Monitoring distance | Night vision | 500meters |
Day vision | 700meters | |
Laser illuminator | Power | 5W |
Wave length | 810nm | |
Illuminating angle | 1°-20° synchronous continuous adjustment | |
Even light | MCIC even light technology | |
Visible light Camera | Sensor | 1/2.8" Progressive Scan CMOS |
Total pixels | 2.1MP | |
Lens | f=4.7-94mm, 20x optical zoom | |
Lens aperture | F1.6-3.5 | |
Minimum illumination | 0.05Lux (color), 0.01Lux (black and white) | |
Electronic shutter speed | Auto and manual adjustment | |
Camera control | Auto gain control, auto white balance, auto backlight compensation, supporting manual and auto day and night mode switch | |
Video coding | Coded format | H.264 |
Video resolution | 1920 x 1080 | |
Bitrate | 64Kbps-4Mbps | |
Frame rate | 1-25f/s(50Hz), 1-30f/s(60Hz) | |
Subtitle overlay | station logo, date, time | |
Image adjustment | brightness, contrast, saturability | |
Supporting protocol | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, 802.1x, QoS, HTTPS, IPv6 (SIP, SRTP optional) | |
Pan-tilt | Angle | Pan 360° continuous, tilt -90° to +90° |
Speed | Pan 0°-80°/s, tilt 0°-60°/s | |
Presets | 256 | |
Cruising function | 6 paths | |
Interface | Network interface | 1×10Base-T/100Base-TX, RJ45 |
Power supply interface | 1×DC 24V socket, for external power adapter | |
Audio interface | 1×Line In, 1×Line Out | |
Alarm interface | 1 switch input, 1 switch output | |
Environmental indicators | Operation temperature | -25℃ to +55℃ (optional -40℃ to +55℃) |
Storage temperature | -40℃ to +65 ℃ | |
Protecting grade | IP66 | |
Anti-vibration | 10-55Hz, 2m/s2, 0.75mm | |
Anti-impact | 150m/s2, 11ms | |
Anti-salt fog | After continuous spraying for 48 hours at PH 6.5-7.2, surface does not change | |
Power supply | Working power supply | DC 24V±5% /2.5A, please use the appendant power supply |
Power consumption | ≤60W | |
Physical features | Size | 240mm×374mm×243mm |
Weight | 8Kg | |
Others | Application function | Real time clock, supporting manual snapshot and manual recording |
Configuration | Supporting configuration management and video browsing through WEB; |
